DRIVE SHAFT EXTENSION COMPONENTS (M0059-G8) для Mercruiser - 198 MIE (2 BBL.) GM 305 V-8 1977 4762210 THRU 6218461

  • №
    Артикул
    Название
  • 1
    59825A9 EXHAUST SEPARATOR
    EXHAUST SEPARATOR
  • 2
    10-37612 SCREW, EXHAUST SEPARATOR (1-1/4")
    SCREW, EXHAUST SEPARATOR (1-1/4")
  • 3
    13-35048 LOCKWASHER, EXHAUST SEPARATOR SCREW
    LOCKWASHER, EXHAUST SEPARATOR SCREW
  • 4
    25-35029 "O" RING
    "O" RING
  • 5
    60931 RETAINER, WATER SHUTTER
    RETAINER, WATER SHUTTER
  • 6
    60930 WATER SHUTTER
    WATER SHUTTER
  • 7
    94018A1 EXHAUST ELBOW ASSEMBLY
    EXHAUST ELBOW ASSEMBLY
  • 8
    10-8M0113174 SCREW, EXHAUST ELBOW TO SEPARATOR
    SCREW, EXHAUST ELBOW TO SEPARATOR
  • 9
    13-58643 LOCKWASHER, EXHAUST ELBOW SCREW
    LOCKWASHER, EXHAUST ELBOW SCREW
  • 10
    32-486594 HOSE, EXHAUST
    HOSE, EXHAUST
  • 11
    54-815504456 CLAMP, EXHAUST HOSE
    CLAMP, EXHAUST HOSE
  • 12
    94608A1 EXHAUST TUBE ASSEMBLY
    EXHAUST TUBE ASSEMBLY
  • 13
    94443A1 EXHAUST ELBOW ASSEMBLY
    EXHAUST ELBOW ASSEMBLY
  • 14
    70981A3 EXHAUST BELLOWS
    EXHAUST BELLOWS
  • 15
    95740 GROUND STRAP, EXHAUST BELLOWS
    GROUND STRAP, EXHAUST BELLOWS
  • 16
    54-815504372 CLAMP, EXHAUST BELLOWS
    CLAMP, EXHAUST BELLOWS
