SHIFT ACTUATOR ASSEMBLY (STERN DRIVE) для Mercruiser - 330 MIE GM 454 V-8 1977-1980 4623115 THRU 5889913

  • №
    Артикул
    Название
  • 1
    69392A4 SHIFT ACTUATOR ASSEMBLY, COMPLETE (SEE NOTE BELOW)
    SHIFT ACTUATOR ASSEMBLY, COMPLETE (SEE NOTE BELOW)
  • 2
    392-4949 ARMATURE
    ARMATURE
  • 3
    392-4960 SPRIING SET, BRUSH
    SPRIING SET, BRUSH
  • 4
    392-4955 HEAD ASSEMBLY, COMMUTATOR END
    HEAD ASSEMBLY, COMMUTATOR END
  • 5
    392-4956 BRUSH SET
    BRUSH SET
  • 6
    392-4962 THRU BOLT
    THRU BOLT
  • 7
    392-5928 FIELD COIL ASSEMBLY
    FIELD COIL ASSEMBLY
  • 8
    392-4951 CRANK ARM ASSEMBLY
    CRANK ARM ASSEMBLY
  • 9
    392-4957 HEAD ASSEMBLY, DRIVE END
    HEAD ASSEMBLY, DRIVE END
  • 10
    392-4959 SCREW, AND DISC PACKAGE
    SCREW, AND DISC PACKAGE
  • 11
    392-4952 GEAR AND GASKET PACKAGE
    GEAR AND GASKET PACKAGE
  • 12
    392-4953 GASKET, COVER
    GASKET, COVER
  • 13
    392-4958 PLATE, CAM
    PLATE, CAM
  • 14
    11-20890 NUT, CRANK ARM
    NUT, CRANK ARM
  • 15
    10-47220 SCREW, COVER ATTACHING (3/8")
    SCREW, COVER ATTACHING (3/8")
  • 16
    84-62995A1 HARNESS ASSEMBLY (3 WIRE LEAD)
    HARNESS ASSEMBLY (3 WIRE LEAD)
  • 17
    42528A6 SWITCH PLATE (INCLUDES 1 PIECE OF REF. NO. 12)
    SWITCH PLATE (INCLUDES 1 PIECE OF REF. NO. 12)
