Choke Plate and Throttle Levers(Design II) для Mercury - V-175 4301235 THRU 0C100860
-
№АртикулНазвание
-
167245T BRACKET, COWL MOUNTING - UPPERBRACKET, COWL MOUNTING - UPPER
-
225-67272 GROMMETGROMMET
-
390435 MOUNTMOUNT
-
412-21249 WASHERWASHER
-
511-35888 NUT, (.250-28)NUT, (.250-28)
-
687076A4 IDLE SPEED CONTROL ASSEMBLYIDLE SPEED CONTROL ASSEMBLY
-
7799831 PLATEPLATE
-
827-672741 GASKETGASKET
-
910-68000 SCREW, (.24-28 X 1.00)SCREW, (.24-28 X 1.00)
-
1012-20583 WASHERWASHER
-
1127-672751 GASKETGASKET
-
1267246T COVERCOVER
-
1310-30720 SCREW, (.250-20 x 2.25)SCREW, (.250-20 x 2.25)
-
1412-29245 WASHER, (.281 x .500 x .060)WASHER, (.281 x .500 x .060)
-
1513-26992 LOCKWASHER, (.250)LOCKWASHER, (.250)
-
1619-90585 PLUGPLUG
-
1767760 THROTTLE LINKTHROTTLE LINK
-
1867759 THROTTLE LEVER
(NON OIL INJECTION)(CENTER/UPPER)THROTTLE LEVER
(NON OIL INJECTION)(CENTER/UPPER) -
1867759 THROTTLE LEVER
(OIL INJECTION)(UPPER)THROTTLE LEVER
(OIL INJECTION)(UPPER) -
1941049 THROTTLE LEVER
(OIL INJECTION)(CENTER)THROTTLE LEVER
(OIL INJECTION)(CENTER) -
2067749 THROTTLE LEVER, LOWERTHROTTLE LEVER, LOWER
-
2110-15124 SCREW, (#10-32 x .750)SCREW, (#10-32 x .750)
-
2213-26996 LOCKWASHER, (#10)LOCKWASHER, (#10)
-
2312-24676 WASHER, (.200 x .440 x .032)WASHER, (.200 x .440 x .032)
-
2417-67297 CLEVIS PINCLEVIS PIN
-
2512-89302 WASHER, (.203 x .406 x .040)WASHER, (.203 x .406 x .040)
-
2618-26953 COTTER PINCOTTER PIN
-
2767748 ROLLERROLLER
-
-27-11338A88 GASKET SET, Engine Overhaul
SN# 6618751 & UpGASKET SET, Engine Overhaul
SN# 6618751 & Up -
-27-79583A81 GASKET SET
SN# 5875204 THRU 6618750GASKET SET
SN# 5875204 THRU 6618750 -
-NLA No Longer Available, Gasket Set
(Refer to Service Bulletin 81-8) SN# USA-5875203/AUS-8072022 & BelowNo Longer Available, Gasket Set
(Refer to Service Bulletin 81-8) SN# USA-5875203/AUS-8072022 & Below
