OIL TANK ASSEMBLY для Arctic Cat ZR 4000 LXR (GREEN) [S2015ZRCEFUSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    2670-447 CAP, OIL TANK
    CAP, OIL TANK
  • 2
    1623-969 SCREW,MAG FORM-TXPH-M6X2.0X12 Z & C
    SCREW,MAG FORM-TXPH-M6X2.0X12 Z & C
  • 3
    1611-564 DECAL, OIL TANK
    DECAL, OIL TANK
  • 4
    0637-456 NECK, OIL FILL
    NECK, OIL FILL
  • 5
    1623-972 O-RING,33MM X 3MM-N70
    O-RING,33MM X 3MM-N70
  • 6
    1623-814 SCREW,MAG FORM-TXPH-M6X2.0X24
    SCREW,MAG FORM-TXPH-M6X2.0X24
  • 7
    1712-968 BRACKET, MOUNTING
    BRACKET, MOUNTING
  • 8
    2670-257 GLASS, SIGHT
    GLASS, SIGHT
  • 9
    0770-964 TANK, OIL
    TANK, OIL
  • 10
    0609-915 SENSOR, LOW OIL (INC. 11)
    SENSOR, LOW OIL (INC. 11)
  • 11
    0609-924 ...GROMMET, SWITCH-OIL LEVEL
    ...GROMMET, SWITCH-OIL LEVEL
  • 12
    0648-441 O-RING,ADJUSTER SHEAVE (2-121)
    O-RING,ADJUSTER SHEAVE (2-121)
  • 13
    2670-229 NIPPLE,OIL TANK-2 STROKE
    NIPPLE,OIL TANK-2 STROKE
  • 14
    1623-042 CLAMP, 10 MM
    CLAMP, 10 MM
  • 15
    0610-692 HOSE, (GREEN) - 25 FT
    HOSE, (GREEN) - 25 FT
  • 15
    0610-693 HOSE, (GREEN) - 100 FT
    HOSE, (GREEN) - 100 FT
  • 16
    1619-345 CONDUIT, FLEXIBLE - 3 FT
    CONDUIT, FLEXIBLE - 3 FT
  • 17
    0124-045 CLAMP,HOSE - .402/.449 DIA (SNP04)
    CLAMP,HOSE - .402/.449 DIA (SNP04)
  • 18
    1048-063 LOCTITE,5699-GASKET MAKER(70ML)
    LOCTITE,5699-GASKET MAKER(70ML)
