TURN SIGNAL ASSY. для Suzuki TU250X K9 - 2009 года выпуска
-
№АртикулНазвание
-
135601-33D30 LAMP ASSY, FRONT TURNSIGNAL (INC 2-8)LAMP ASSY, FRONT TURNSIGNAL (INC 2-8)
-
235612-38A01 LENSLENS
-
335613-38A00 GASKETGASKET
-
403211-0425B SCREWSCREW
-
535627-43010 GASKETGASKET
-
635619-45C10 STAY, TURNSIGNAL, FRONTSTAY, TURNSIGNAL, FRONT
-
709471-12045 BULB (12V21W)BULB (12V21W)
-
835623-38A01 SCREWSCREW
-
935698-01480 COVER, TURNSIGNAL LEADCOVER, TURNSIGNAL LEAD
-
1008316-1010B NUTNUT
-
1135603-33D40 LAMP ASSY, REAR TURNSIGNAL, RIGHT (INC 13-19)LAMP ASSY, REAR TURNSIGNAL, RIGHT (INC 13-19)
-
1235604-33D40 LAMP ASSY, REAR TURNSIGNAL, LEFT (INC 13-19)LAMP ASSY, REAR TURNSIGNAL, LEFT (INC 13-19)
-
1335652-38A21 LENSLENS
-
1435613-38A00 GASKETGASKET
-
1503211-0425A SCREWSCREW
-
1635627-43010 GASKETGASKET
-
1735619-45C10 STAY, TURNSIGNALSTAY, TURNSIGNAL
-
1809471-12045 BULB (12V21W)BULB (12V21W)
-
1935623-38A01 SCREWSCREW
-
2035621-26G20 BRACKET, REAR TURNSIGNAL, RIGHTBRACKET, REAR TURNSIGNAL, RIGHT
-
2135641-26G20 BRACKET, REAR TURNSIGNAL, LEFTBRACKET, REAR TURNSIGNAL, LEFT
-
2209403-07315 CLAMP, REAR TURNSIGNALCLAMP, REAR TURNSIGNAL
-
2309407-14407 CLAMP (L:145)CLAMP (L:145)
-
2401550-0625B BOLTBOLT
-
2508316-1010B NUTNUT
-
2638610-03F00 RELAY ASSY, TURNSIGNALRELAY ASSY, TURNSIGNAL
