WATER PIPE для Kawasaki Vulcan 2000 Limited - 2006 года выпуска

  • №
    Артикул
    Название
  • 120
    120R0614 BOLT, SOCKET, 6X14
    BOLT, SOCKET, 6X14
  • 120A
    120R0616 BOLT, SOCKET, 6X16
    BOLT, SOCKET, 6X16
  • 120B
    120W0612 BOLT, SOCKET, 6X12 (EXCEPT CALIF.)
    BOLT, SOCKET, 6X12 (EXCEPT CALIF.)
  • 11009
    11009-1145 GASKET, RESERVOIR TANK CAP
    GASKET, RESERVOIR TANK CAP
  • 11053
    11053-0733 BRACKET, THERMOSTAT
    BRACKET, THERMOSTAT
  • 11065
    11065-0063 CAP
    CAP
  • 14075
    14075-0001 CAP, ASSY
    CAP, ASSY
  • 16160
    16160-0095 BODY, THERMOSTAT
    BODY, THERMOSTAT
  • 31064
    31064-0011 PIPE, COMP (EXCEPT CALIF.)
    PIPE, COMP (EXCEPT CALIF.)
  • 39062
    39062-0004 HOSE, COOLING, THERMO, PIPE
    HOSE, COOLING, THERMO, PIPE
  • 39062A
    39062-0005 HOSE, COOLING, THERMO, RADIATOR
    HOSE, COOLING, THERMO, RADIATOR
  • 39062B
    39062-0008 HOSE, COOLING, RADIATOR, PIPE
    HOSE, COOLING, RADIATOR, PIPE
  • 39062C
    39062-0009 HOSE, COOLING, PIPE, WATER PUMP
    HOSE, COOLING, PIPE, WATER PUMP
  • 39062D
    39062-0047 HOSE, COOLING, THERMO, PIPE
    HOSE, COOLING, THERMO, PIPE
  • 39062E
    39062-0062 HOSE, COOLING, RESERVOIR, PIPE
    HOSE, COOLING, RESERVOIR, PIPE
  • 39062F
    39062-0064 HOSE, COOLING, REAR HEAD, PIPE
    HOSE, COOLING, REAR HEAD, PIPE
  • 39192
    39192-0001 PIPE, WATER
    PIPE, WATER
  • 39192A
    39192-0007 PIPE, WATER, REAR HEAD
    PIPE, WATER, REAR HEAD
  • 39192B
    39192-0008 PIPE, WATER, FRONT HEAD
    PIPE, WATER, FRONT HEAD
  • 39192C
    39192-0009 PIPE, WATER, RADIATOR, W/P
    PIPE, WATER, RADIATOR, W/P
  • 43078
    43078-0020 RESERVOIR
    RESERVOIR
  • 49054
    49054-1067 THERMOSTAT
    THERMOSTAT
  • 49085
    49085-1066 CAP, ASSY, PRESSURE
    CAP, ASSY, PRESSURE
  • 92001
    92001-1950 BOLT, 6X16
    BOLT, 6X16
  • 92009
    92009-1341 SCREW, 5X14
    SCREW, 5X14
  • 92022
    92022-304 WASHER, 6.2X11X1
    WASHER, 6.2X11X1
  • 92037
    92037-147 CLAMP, TUBE
    CLAMP, TUBE
  • 92037A
    92037-1505 CLAMP, TUBE
    CLAMP, TUBE
  • 92055
    92055-112 O-RING, 53.5X2.6
    O-RING, 53.5X2.6
  • 92055A
    92055-1258 O-RING, 16.8X2.4
    O-RING, 16.8X2.4
  • 92170
    92170-1493 CLAMP
    CLAMP
  • 92171
    92171-0179 CLAMP
    CLAMP
  • 92171A
    92171-0209 CLAMP (EXCEPT CALIF.)
    CLAMP (EXCEPT CALIF.)
  • 92171B
    92171-0261 CLAMP
    CLAMP
  • 92171C
    92171-0334 CLAMP
    CLAMP
  • 92171D
    92171-0338 CLAMP
    CLAMP
  • 92192
    92192-0010 TUBE, 7X10X120
    TUBE, 7X10X120
  • 130
    130L0612 BOLT, FLANGED, 6X12
    BOLT, FLANGED, 6X12
  • 132
    132L0610 BOLT, FLANGED, SMALL, 6X10
    BOLT, FLANGED, SMALL, 6X10
  • 132A
    132L0612 BOLT, FLANGED, SMALL, 6X12
    BOLT, FLANGED, SMALL, 6X12
  • 670
    670B2020 O-RING, 20MM
    O-RING, 20MM
