WATER PUMP ASSEMBLY для Arctic Cat XF 9000 HIGH COUNTRY LTD 153 2.2 BLACK INTERNATIONAL - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    3020-300 PUMP, WATER - ASSEMBLY (INC. 2-10 AND ONE NO. 11)
    PUMP, WATER - ASSEMBLY (INC. 2-10 AND ONE NO. 11)
  • 2
    3020-301 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 3
    3020-302 ...COVER, HOUSING
    ...COVER, HOUSING
  • 4
    3020-303 ...SEAL, HOUSING COVER
    ...SEAL, HOUSING COVER
  • 5
    3020-304 ...IMPELLER/SHAFT ASSEMBLY
    ...IMPELLER/SHAFT ASSEMBLY
  • 6
    3020-305 ...PIN, DOWEL
    ...PIN, DOWEL
  • 7
    3020-306 ...SEAL, MECHANICAL
    ...SEAL, MECHANICAL
  • 8
    3020-307 ...SEAL, OIL
    ...SEAL, OIL
  • 9
    3020-308 ...GEAR
    ...GEAR
  • 10
    3020-309 ...RING, RETAINING
    ...RING, RETAINING
  • 11
    3020-310 ...BEARING
    ...BEARING
  • 12
    3020-293 PIN, DOWEL
    PIN, DOWEL
  • 13
    3020-311 SEAL
    SEAL
  • 14
    3020-312 SEAL
    SEAL
  • 15
    3020-313 RING, RETAINING
    RING, RETAINING
  • 16
    3020-314 SCREW, CAP
    SCREW, CAP
  • 17
    3020-315 SCREW, CAP
    SCREW, CAP
  • 18
    3020-316 CLAMP, HOSE
    CLAMP, HOSE
  • 19
    3020-583 HOSE, COOLANT - WATER PUMP/THROTTLE BODY
    HOSE, COOLANT - WATER PUMP/THROTTLE BODY
  • 20
    3020-318 CLAMP, HOSE
    CLAMP, HOSE
  • 21
    3020-319 HOSE, COOLANT - WATER PUMP/OIL COOLER
    HOSE, COOLANT - WATER PUMP/OIL COOLER
  • 22
    3020-320 COOLER, OIL - ASSEMBLY (INC. 23)
    COOLER, OIL - ASSEMBLY (INC. 23)
  • 23
    3020-321 ...O-RING
    ...O-RING
  • 24
    3020-322 SCREW, CAP
    SCREW, CAP
  • 25
    3020-581 HOSE, COOLANT - OIL COOLER/ELBOW FITTING
    HOSE, COOLANT - OIL COOLER/ELBOW FITTING
  • 26
    3020-167 SCREW, CAP
    SCREW, CAP
  • 27
    3020-402 FITTING, ELBOW
    FITTING, ELBOW
  • 28
    3020-325 O-RING
    O-RING
  • 29
    3020-580 HOSE, COOLANT - ELBOW FITTING/WATER PUMP
    HOSE, COOLANT - ELBOW FITTING/WATER PUMP
  • 30
    3020-582 CLAMP, HOSE
    CLAMP, HOSE
