EXHAUST ASSEMBLY для Arctic Cat XF 9000 HIGH COUNTRY LTD 153 2.2 BLACK INTERNATIONAL - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    2712-008 RESONATOR, EXHAUST - ASSEMBLY (INC. 2-4 AND 11-12)
    RESONATOR, EXHAUST - ASSEMBLY (INC. 2-4 AND 11-12)
  • 2
    8061-682 ...RIVET
    ...RIVET
  • 3
    3612-180 ...SHIELD, HEAT - RIGHT
    ...SHIELD, HEAT - RIGHT
  • 4
    3612-276 ...PACKING, RESONATOR - OUTER
    ...PACKING, RESONATOR - OUTER
  • 5
    2623-207 SCREW, CAP
    SCREW, CAP
  • 6
    2612-186 GROMMET
    GROMMET
  • 7
    8060-710 RIVET
    RIVET
  • 8
    3612-194 GASKET
    GASKET
  • 9
    2612-912 GROMMET
    GROMMET
  • 10
    1712-790 BRACKET, MOUNTING - LOWER
    BRACKET, MOUNTING - LOWER
  • 11
    3612-181 SHIELD, HEAT - LEFT
    SHIELD, HEAT - LEFT
  • 12
    3612-182 PACKING, RESONATOR
    PACKING, RESONATOR
  • 13
    1623-052 CLIP, U-NUT
    CLIP, U-NUT
  • 14
    2623-164 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 15
    2712-061 SHIELD, HEAT W/GROMMETS
    SHIELD, HEAT W/GROMMETS
  • 16
    8050-223 WASHER, FLAT
    WASHER, FLAT
  • 17
    2623-232 SCREW, CAP
    SCREW, CAP
  • 18
    3612-159 SHIELD, HEAT
    SHIELD, HEAT
  • 19
    2712-082 SHIELD, HEAT - W/ISOLATORS (INC. 20-21)
    SHIELD, HEAT - W/ISOLATORS (INC. 20-21)
  • 20
    2623-231 ...ISOLATOR, WASHER - FLAT
    ...ISOLATOR, WASHER - FLAT
  • 21
    2623-230 ...ISOLATOR, WASHER - STEP
    ...ISOLATOR, WASHER - STEP
  • 22
    2712-043 PIPE, EXHAUST
    PIPE, EXHAUST
  • 23
    3612-135 SHIELD, HEAT - MANIFOLD
    SHIELD, HEAT - MANIFOLD
  • 24
    8476-516 SCREW, MACHINE
    SCREW, MACHINE
  • 25
    8050-217 WASHER
    WASHER
  • 26
    1623-637 CLIP, U-NUT
    CLIP, U-NUT
  • 27
    3020-384 MANIFOLD
    MANIFOLD
  • 28
    3020-458 GASKET
    GASKET
  • 29
    3020-385 NUT
    NUT
  • 30
    8476-612 SCREW, MACHINE
    SCREW, MACHINE
  • 31
    8053-212 WASHER, EXTERNAL TOOTH LOCK
    WASHER, EXTERNAL TOOTH LOCK
  • 32
    1623-409 RETAINER, PUSHNUT
    RETAINER, PUSHNUT
  • 33
    3612-134 CLAMP, EXHAUST (INC. 34)
    CLAMP, EXHAUST (INC. 34)
  • 34
    3612-272 ...BOLT W/NUT
    ...BOLT W/NUT
  • 35
    0612-668 SPRING
    SPRING
