CAMSHAFT- CHAIN- AND VALVE ASSEMBLY для Arctic Cat XF 9000 HIGH COUNTRY LTD 153 2.2 BLACK INTERNATIONAL - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    3020-438 VALVE, INTAKE
    VALVE, INTAKE
  • 2
    3020-440 SEAT, SPRING
    SEAT, SPRING
  • 3
    3020-442 SEAL
    SEAL
  • 4
    3020-441 SPRING, VALVE
    SPRING, VALVE
  • 5
    3020-240 RETAINER, SPRING
    RETAINER, SPRING
  • 6
    3020-241 COTTER, VALVE
    COTTER, VALVE
  • 7
    3020-242 SHIM, TAPPET - 1.20 MM
    SHIM, TAPPET - 1.20 MM
  • 7
    3020-243 SHIM, TAPPET - 1.25 MM
    SHIM, TAPPET - 1.25 MM
  • 7
    3020-244 SHIM, TAPPET - 1.30 MM
    SHIM, TAPPET - 1.30 MM
  • 7
    3020-245 SHIM, TAPPET - 1.35 MM
    SHIM, TAPPET - 1.35 MM
  • 7
    3020-246 SHIM, TAPPET - 1.40 MM
    SHIM, TAPPET - 1.40 MM
  • 7
    3020-247 SHIM, TAPPET - 1.45 MM
    SHIM, TAPPET - 1.45 MM
  • 7
    3020-248 SHIM, TAPPET - 1.50 MM
    SHIM, TAPPET - 1.50 MM
  • 7
    3020-249 SHIM, TAPPET - 1.55 MM
    SHIM, TAPPET - 1.55 MM
  • 7
    3020-250 SHIM, TAPPET - 1.60 MM
    SHIM, TAPPET - 1.60 MM
  • 7
    3020-251 SHIM, TAPPET - 1.65 MM
    SHIM, TAPPET - 1.65 MM
  • 7
    3020-252 SHIM, TAPPET - 1.70 MM
    SHIM, TAPPET - 1.70 MM
  • 7
    3020-253 SHIM, TAPPET - 1.75 MM
    SHIM, TAPPET - 1.75 MM
  • 7
    3020-254 SHIM, TAPPET - 1.80 MM
    SHIM, TAPPET - 1.80 MM
  • 7
    3020-255 SHIM, TAPPET - 1.85 MM
    SHIM, TAPPET - 1.85 MM
  • 7
    3020-256 SHIM, TAPPET - 1.90 MM
    SHIM, TAPPET - 1.90 MM
  • 7
    3020-257 SHIM, TAPPET - 1.95 MM
    SHIM, TAPPET - 1.95 MM
  • 7
    3020-258 SHIM, TAPPET - 2.00 MM
    SHIM, TAPPET - 2.00 MM
  • 7
    3020-259 SHIM, TAPPET - 2.05 MM
    SHIM, TAPPET - 2.05 MM
  • 7
    3020-260 SHIM, TAPPET - 2.10 MM
    SHIM, TAPPET - 2.10 MM
  • 7
    3020-261 SHIM, TAPPET - 2.15 MM
    SHIM, TAPPET - 2.15 MM
  • 7
    3020-262 SHIM, TAPPET - 2.20 MM
    SHIM, TAPPET - 2.20 MM
  • 7
    3020-263 SHIM, TAPPET - 2.25 MM
    SHIM, TAPPET - 2.25 MM
  • 7
    3020-264 SHIM, TAPPET - 2.30 MM
    SHIM, TAPPET - 2.30 MM
  • 7
    3020-265 SHIM, TAPPET - 2.35 MM
    SHIM, TAPPET - 2.35 MM
  • 7
    3020-266 SHIM, TAPPET - 2.40 MM
    SHIM, TAPPET - 2.40 MM
  • 8
    3020-267 TAPPET - YELLOW
    TAPPET - YELLOW
  • 8
    3020-268 TAPPET - GREEN
    TAPPET - GREEN
  • 9
    3020-439 VALVE, EXHAUST
    VALVE, EXHAUST
  • 10
    3020-445 CAMSHAFT, INTAKE
    CAMSHAFT, INTAKE
  • 11
    3020-446 CAMSHAFT, EXHAUST
    CAMSHAFT, EXHAUST
  • 12
    3020-447 SPROCKET
    SPROCKET
  • 13
    3020-273 SCREW, CAP
    SCREW, CAP
  • 14
    3020-274 CHAIN, CAM
    CHAIN, CAM
  • 15
    3020-275 GUIDE, CAM CHAIN
    GUIDE, CAM CHAIN
  • 16
    3020-451 SCREW, SHOULDER
    SCREW, SHOULDER
  • 17
    3020-450 TENSIONER, CAM CHAIN
    TENSIONER, CAM CHAIN
  • 18
    3020-278 GASKET
    GASKET
  • 19
    3020-448 ADJUSTER, TENSIONER - ASSEMBLY
    ADJUSTER, TENSIONER - ASSEMBLY
  • 20
    3020-280 SCREW, CAP
    SCREW, CAP
