SUSPENSION - REAR TRACK для Polaris 500 CLASSIC TOURING (S03ST4BS) - 2003 года выпуска
-
№АртикулНазвание
-
17517247 SCREW,SCREW,
-
27552603 WASHER, SPRING LOCKWASHER, SPRING LOCK
-
37710439 RING, RETAININGRING, RETAINING
-
41594067 WHEEL, BOGIEWHEEL, BOGIE
-
51541025-067 TENSIONER, SHAFT (BLACK)TENSIONER, SHAFT (BLACK)
-
67542439 NUT, NYLOKNUT, NYLOK
-
77555806 WASHER, FLATWASHER, FLAT
-
87517731 BOLTBOLT
-
97556130 WASHERWASHER
-
101590303-244 WHEEL IDLER, ASSY. (BR SILVER METALLIC)WHEEL IDLER, ASSY. (BR SILVER METALLIC)
-
115432535 SPACER, IDLERSPACER, IDLER
-
127555918 BUSHINGBUSHING
-
131594087 WHEEL ASSY., PLAIN (6.38 O.D.)WHEEL ASSY., PLAIN (6.38 O.D.)
-
145333285 SPACER, IDLER, LONGSPACER, IDLER, LONG
-
155020744 SHAFT, IDLERSHAFT, IDLER
-
167555893 WASHER, FLATWASHER, FLAT
-
177517921 SCREWSCREW
-
187556301 BUSHINGBUSHING
-
195332784 SPACER, OUTERSPACER, OUTER
-
205020724 SHAFT, PIVOT ARMSHAFT, PIVOT ARM
-
225332783 TUBE, SUSPENSIONTUBE, SUSPENSION
-
237517380 SCREWSCREW
-
245411091 TRACK, LIGHTNING (133"X.82)TRACK, LIGHTNING (133"X.82)
-
245241473 CLIP, SLIDECLIP, SLIDE
-
245241474 CLIP, GUIDECLIP, GUIDE
-
257080424 FITTING, LUBE.FITTING, LUBE.
-
261012267-067 SHAFT, LIMITER STRAP (BLACK)SHAFT, LIMITER STRAP (BLACK)
-
271540968-067 ARM, SHOCK PIVOTARM, SHOCK PIVOT
-
285333404 SHAFTSHAFT
-
295131112 BOSS, BOLT HEADBOSS, BOLT HEAD
-
305020649 SHAFT, SHOCK BRACKET (REAR)SHAFT, SHOCK BRACKET (REAR)
-
317542411 NUT FLEXLOCNUT FLEXLOC
-
321541141-067 ARM, PIVOT (BLACK) (REAR)ARM, PIVOT (BLACK) (REAR)
