OIL TANK W/ AIR BOX ASSEMBLY для Polaris 500 CLASSIC TOURING (S03ST4BS) - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    4040040 SENSOR, OIL LEVEL, W/CONN.
    SENSOR, OIL LEVEL, W/CONN.
  • 2
    5430779 CAP, OIL TANK
    CAP, OIL TANK
  • 3
    5810141 GASKET, OIL CAP
    GASKET, OIL CAP
  • 4
    7558302 WASHER, WROUGHT
    WASHER, WROUGHT
  • 5
    7512276 BOLT
    BOLT
  • 6
    8450003-1525 FUEL LINE (1/4 ID, 1525 CM.)
    FUEL LINE (1/4 ID, 1525 CM.)
  • 7
    2530009 FILTER, IN-LINE (SMALL)
    FILTER, IN-LINE (SMALL)
  • 8
    4010051 CONDUIT, CONVOL (30 CM)
    CONDUIT, CONVOL (30 CM)
  • 9
    7080307 CLAMP, HOSE
    CLAMP, HOSE
  • 10
    7052042 FITTING, OUTLET
    FITTING, OUTLET
  • 11
    5241334 BRACKET, OILTANK, COINED
    BRACKET, OILTANK, COINED
  • 12
    7661637 RIVET, INTERLOCK Z
    RIVET, INTERLOCK Z
  • 13
    5431437 TANK, OIL
    TANK, OIL
  • 14
    7670096 NUT
    NUT
  • 15
    7052095 FITTING (90 DEG, 1/8)
    FITTING (90 DEG, 1/8)
  • 16
    8450061-600 FUELLINE (3MMX7MM)
    FUELLINE (3MMX7MM)
  • 17
    4020139 CLIP, PLASTIC
    CLIP, PLASTIC
  • 19
    7512222 SCREW
    SCREW
  • 20
    7512279 SCREW
    SCREW
  • 21
    7552604 WASHER
    WASHER
  • 22
    5242767-067 BRACKET, SLNCR/REMOTE FLR (BLACK)
    BRACKET, SLNCR/REMOTE FLR (BLACK)
  • 23
    7541923 NUT, WELL
    NUT, WELL
  • 24
    7555843 WASHER, WROUGHT
    WASHER, WROUGHT
  • 25
    5850075 PLATE, AIR SILENCER
    PLATE, AIR SILENCER
  • 26
    7052077 FITTING
    FITTING
  • 27
    5410271 BOOT
    BOOT
  • 28
    5434075 SILENCER, INTAKE DRILLED
    SILENCER, INTAKE DRILLED
  • 29
    5211274 BRACKET, SILENCER
    BRACKET, SILENCER
  • 30
    1253102 BAFFLE ASSY.
    BAFFLE ASSY.
  • 31
    7075351 DECAL, CAUTION
    DECAL, CAUTION
  • 32
    7073820 DECAL, ADJUSTDRIVEN CLUTCH
    DECAL, ADJUSTDRIVEN CLUTCH
  • 33
    7670055 CLIP, AIR BOX
    CLIP, AIR BOX
  • 34
    7073426 DECAL, GREASING
    DECAL, GREASING
  • 35
    5811628 FOAM, AIRBOX CHIMNEY, HYB.
    FOAM, AIRBOX CHIMNEY, HYB.
  • 36
    5432939 CVR, AIR SILENCER, DRILLED
    CVR, AIR SILENCER, DRILLED
  • 37
    7075359 DECAL, COOLING SYSTEM
    DECAL, COOLING SYSTEM
