CARBURETOR ASSEMBLY для Polaris TRAIL TOURING (S02ST5BS) - 2002 года выпуска
-
№АртикулНазвание
-
13130877 TOP ASSY.TOP ASSY.
-
23130439 SPRING, THROTTLESPRING, THROTTLE
-
33130879 PLATEPLATE
-
43131246 NEEDLE, JET (6BGY16-2)NEEDLE, JET (6BGY16-2)
-
53130199 HOLDER, GUIDEHOLDER, GUIDE
-
63130884 SPRING, PLUNGERSPRING, PLUNGER
-
73130328 PLUNGER ASSY., STARTERPLUNGER ASSY., STARTER
-
83130010 SPRING, THROTTLE ADJUSTSPRING, THROTTLE ADJUST
-
93130437 SCREW, THROTTLE STOPSCREW, THROTTLE STOP
-
103130011 SCREW, AIRSCREW, AIR
-
113130012 SPRING, AIR ADJUSTSPRING, AIR ADJUST
-
123130066 JET, PILOT (#35)JET, PILOT (#35)
-
133130025 SCREW AND WASHERSCREW AND WASHER
-
147080003 CLAMP, HOSECLAMP, HOSE
-
155431893 PLUG, TRAPPLUG, TRAP
-
168350017-600 FUEL LINE, ETHER (5/16'') (RED)FUEL LINE, ETHER (5/16'') (RED)
-
175020476 FITTING, SEDIMENTFITTING, SEDIMENT
-
183130239 O-RINGO-RING
-
193130133 JET, MAIN (#300)JET, MAIN (#300)
-
203130014 WASHERWASHER
-
213130430 FLOAT ASSY.FLOAT ASSY.
-
223130237 CAPCAP
-
233130020 PACKING, FLOAT CHAMBERPACKING, FLOAT CHAMBER
-
243131146 VALVE, NEEDLE (1.5)VALVE, NEEDLE (1.5)
-
253130017 PACKINGPACKING
-
263130018 ARM, FLOATARM, FLOAT
-
273130361 PIN, FLOATPIN, FLOAT
-
283130954 CARBURETOR ASSY. (INCL. 1-13, 17-33)CARBURETOR ASSY. (INCL. 1-13, 17-33)
-
293083337 VALVE, CHECK ASSY.VALVE, CHECK ASSY.
-
303130479 CAPCAP
-
313130894 JET, NEEDLEJET, NEEDLE
-
323130372 VALVE, THROTTLE (3.0)VALVE, THROTTLE (3.0)
-
333130508 E-RINGE-RING
-
343085932 HOSEHOSE
