SUSPENSION - REAR TORQUE ARM ASSEMBLY для Polaris 600 CLASSIC (S02ND6ES) - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    5132578 SHAFT,UPR.TORQUE ARM,M-10
    SHAFT,UPR.TORQUE ARM,M-10
  • 2
    1541527-216 WELD-TORQUE ARM,M-10,YELLOW
    WELD-TORQUE ARM,M-10,YELLOW
  • 3
    7542439 NUT,NYLOK
    NUT,NYLOK
  • 4
    7515415 BOLT
    BOLT
  • 5
    7080424 FITTING, LUBE.
    FITTING, LUBE.
  • 6
    5133093 SHAFT-RTA LOWER
    SHAFT-RTA LOWER
  • 7
    7079432 DECAL-M-10,FOX,RES
    DECAL-M-10,FOX,RES
  • 8
    1590308 WHEEL ASSY.,OFF-SET 5.60
    WHEEL ASSY.,OFF-SET 5.60
  • 8
    3514330 BEARING-6206
    BEARING-6206
  • 8
    7710486 CLIP
    CLIP
  • 9
    5132582 COLLAR-BRG LOCK,REAR
    COLLAR-BRG LOCK,REAR
  • 9
    7512257 SCREW-SET
    SCREW-SET
  • 10
    7555984 WASHER ,
    WASHER ,
  • 11
    7552614 WASHER, LOCK
    WASHER, LOCK
  • 12
    7517815 SCREW-7/16-14X1.25SOCHD-P80-DGPT
    SCREW-7/16-14X1.25SOCHD-P80-DGPT
  • 14
    7041934 SHOCK-REAR TRACK
    SHOCK-REAR TRACK
  • 15
    5333905 SLEEVE,.385X.560X1.24
    SLEEVE,.385X.560X1.24
  • 16
    5244747 CAP-ICE
    CAP-ICE
  • 17
    5020618 RETAINER,SPRING,SLOTTED
    RETAINER,SPRING,SLOTTED
  • 18
    5132645 NUT-PRELOAD
    NUT-PRELOAD
  • 19
    7041935-216 SPRING-REAR SHOCK,M10,SCR YLW
    SPRING-REAR SHOCK,M10,SCR YLW
  • 20
    5433882 BUSHING-OVER LOAD DEPRESSOR
    BUSHING-OVER LOAD DEPRESSOR
  • 21
    5133032 RETAINER-REAR SPRING
    RETAINER-REAR SPRING
  • 22
    7041936-067 SPRING-REAR OVER/LOAD,M-10,BLK
    SPRING-REAR OVER/LOAD,M-10,BLK
  • 23
    5132625 RING-ADJUSTER
    RING-ADJUSTER
  • 24
    5132643 NUT-RING ADJUSTER
    NUT-RING ADJUSTER
  • 25
    5132794 SLEEVE-OVERLOAD DEPRESSOR
    SLEEVE-OVERLOAD DEPRESSOR
