SEAT W/ GAS TANK ASSEMBLY для Polaris 600 CLASSIC (S02ND6ES) - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    2511195-070 CAP ASSY,FUEL,BLK
    CAP ASSY,FUEL,BLK
  • 1
    5810512 GASKET, FUEL CAP
    GASKET, FUEL CAP
  • 2
    2682759 SEAT ASSY.,EDGE (INCL. 2-13)
    SEAT ASSY.,EDGE (INCL. 2-13)
  • 2
    2682760 SEAT COVER ASSY.,EDGE
    SEAT COVER ASSY.,EDGE
  • 3
    7080550 GROMMET,RELATCH,1",BOTT.
    GROMMET,RELATCH,1",BOTT.
  • 4
    7080549 GROMMET,RELATCH,1",TOP
    GROMMET,RELATCH,1",TOP
  • 5
    7080548 TWISTLOCK,RELATCH,1",W/HOLE
    TWISTLOCK,RELATCH,1",W/HOLE
  • 6
    7621337 RIVET
    RIVET
  • 7
    4030024 BULB,TAILLIGHT
    BULB,TAILLIGHT
  • 8
    4030045 BULB, BRAKELIGHT
    BULB, BRAKELIGHT
  • 9
    5430423 LENS,TAILLIGHT
    LENS,TAILLIGHT
  • 10
    7511840 SCREW
    SCREW
  • 11
    5433341 HOUSING-TAILLIGHT
    HOUSING-TAILLIGHT
  • 12
    2460399 HARNESS, TAILLIGHT
    HARNESS, TAILLIGHT
  • 13
    5243185 RETAINER-CLIP,TOOL POUCH
    RETAINER-CLIP,TOOL POUCH
  • 14
    7555727 RIVET BURR
    RIVET BURR
  • 15
    7621319 RIVET
    RIVET
  • 16
    7558301 WASHER
    WASHER
  • 17
    7515159 SCREW
    SCREW
  • 18
    5631194 NUT-SEAT
    NUT-SEAT
  • 19
    7621472 RIVET
    RIVET
  • 20
    7542122 NUT-LOCK
    NUT-LOCK
  • 21
    7555960 WASHER
    WASHER
  • 22
    7670021 SPEED NUT
    SPEED NUT
  • 23
    7512193 BOLT
    BOLT
  • 24
    5810947 SEAL,FOAM,R.COOLER
    SEAL,FOAM,R.COOLER
  • 25
    7052301 PICK-UP-FUEL,W/FILTER,105MICRN
    PICK-UP-FUEL,W/FILTER,105MICRN
  • 26
    7080402 RING, COMPRESSION
    RING, COMPRESSION
  • 27
    8350019-600 FUEL LINE-ESTER
    FUEL LINE-ESTER
  • 28
    7052028 GROMMET-TANK FITTING
    GROMMET-TANK FITTING
  • 29
    7052259 FITTING,1/4" 90Ш DEX
    FITTING,1/4" 90Ш DEX
  • 30
    2520264 FUEL TANK ASSY., EDGE,12 GAL W/SD (INCL. 25-33)
    FUEL TANK ASSY., EDGE,12 GAL W/SD (INCL. 25-33)
  • 31
    2410165 SENDER-FUEL,12.0 GAL,SNOW
    SENDER-FUEL,12.0 GAL,SNOW
  • 32
    2410232 HARDWARE,PKG,SENDER
    HARDWARE,PKG,SENDER
  • 33
    7052095 FITTING,90 DEG,1/8,
    FITTING,90 DEG,1/8,
  • 34
    8450061-600 FUELLINE,3MMX7MM
    FUELLINE,3MMX7MM
  • 35
    7080804 CABLE TIE-RELEASABLE,5 1/2"
    CABLE TIE-RELEASABLE,5 1/2"
