RAIL ASSEMBLY W/ IDLER WHEELS для Polaris 600 CLASSIC (S02ND6ES) - 2002 года выпуска

  • №
    Артикул
    Название
  • 13
    1541676-309 RAIL ASSY.,M-10, (LEFT),NATURAL (INCL. 1-3,13,17,18,27,35)
    RAIL ASSY.,M-10, (LEFT),NATURAL (INCL. 1-3,13,17,18,27,35)
  • 13
    1541677-309 RAIL ASSY.,M-10, (RIGHT),NATURAL (INCL. 1-3,13,17,18,27,35)
    RAIL ASSY.,M-10, (RIGHT),NATURAL (INCL. 1-3,13,17,18,27,35)
  • 1
    7541925 NUT
    NUT
  • 2
    7555792 WASHER
    WASHER
  • 3
    5434374 CAP-RAIL TIP
    CAP-RAIL TIP
  • 4
    7542324 NUT
    NUT
  • 5
    7558402 WASHER STEEL
    WASHER STEEL
  • 6
    5132577 BLOCK-RAIL SUPPORT
    BLOCK-RAIL SUPPORT
  • 7
    7661845 RIVET
    RIVET
  • 8
    5244651 PLATE-RAIL SUPPORT
    PLATE-RAIL SUPPORT
  • 9
    7718407 RING-RETAINING (1 PER WHEEL)
    RING-RETAINING (1 PER WHEEL)
  • 10
    3514303 BEARING (1 PER WHEEL)
    BEARING (1 PER WHEEL)
  • 11
    1590275-312 SCROLLED WHEEL ASSY.,5.35,BLUE (INCL. 9,10)
    SCROLLED WHEEL ASSY.,5.35,BLUE (INCL. 9,10)
  • 12
    7555783 WASHER
    WASHER
  • 13
    5411947 BUMPER-JOUNCE,RAIL
    BUMPER-JOUNCE,RAIL
  • 14
    7512392 BOLT
    BOLT
  • 15
    7517773 SCR,7/16-14X3 3/4XHD
    SCR,7/16-14X3 3/4XHD
  • 16
    5132712 NUT-TENSION,ADJ,7/16-14
    NUT-TENSION,ADJ,7/16-14
  • 17
    7621501 RIVET,
    RIVET,
  • 18
    5132611 BLOCK-IDLER BOLT ADJ,THIN,7/16
    BLOCK-IDLER BOLT ADJ,THIN,7/16
  • 19
    5631103 GUIDE-SLIDER,M-10, (LEFT)
    GUIDE-SLIDER,M-10, (LEFT)
  • 19
    5631104 GUIDE-SLIDER,M-10, (RIGHT)
    GUIDE-SLIDER,M-10, (RIGHT)
  • 20
    5245045 PLATE-COUPLER BLOCK
    PLATE-COUPLER BLOCK
  • 21
    7512310 SCREW
    SCREW
  • 22
    5434239 BLOCK-SLIDER,LONG,M-10, (LEFT)
    BLOCK-SLIDER,LONG,M-10, (LEFT)
  • 22
    5434240 BLOCK-SLIDER,LONG,M-10, (RIGHT)
    BLOCK-SLIDER,LONG,M-10, (RIGHT)
  • 23
    5132584 BLOCK-SHOCK PIVOT THREADED
    BLOCK-SHOCK PIVOT THREADED
  • 24
    7515511 SCREW
    SCREW
  • 25
    7542404 NUT
    NUT
  • 26
    5133009 SPACER-.390X.56X.43
    SPACER-.390X.56X.43
  • 27
    7511967 BOLT
    BOLT
  • 28
    5132832 CLAMP-RESERVIOR,M10
    CLAMP-RESERVIOR,M10
  • 29
    7515319 BOLT
    BOLT
  • 30
    7515382 BOLT
    BOLT
  • 31
    7556179 WASHER-SPRING,CON 5/16X.090-Y (
    WASHER-SPRING,CON 5/16X.090-Y (
  • 32
    5131314 MOUNT,WHEEL,MACH
    MOUNT,WHEEL,MACH
  • 33
    7512329 BOLT
    BOLT
  • 34
    5521563-309 HI-FAX-M-10,NATURAL
    HI-FAX-M-10,NATURAL
  • 35
    7511975 SCREW
    SCREW
  • 36
    7515199 SCREW
    SCREW
