GEAR SELECTOR для Polaris XPLORER (A00AG25CA) - 2000 года выпуска
-
№АртикулНазвание
-
13233195 GEAR SELECT KNOB ASSY. (BLACK)GEAR SELECT KNOB ASSY. (BLACK)
-
27512024 SCREWSCREW
-
33233131 STRAP, WIRESTRAP, WIRE
-
43233649 SCREWSCREW
-
53233648 COVER, GEAR SELECTOR BOOTCOVER, GEAR SELECTOR BOOT
-
63233646 PLASTIC, SPHEREPLASTIC, SPHERE
-
73233645 PIN, DOWELPIN, DOWEL
-
83233727 HANDLE, SUB ASSY. GEAR SELECTORHANDLE, SUB ASSY. GEAR SELECTOR
-
93233643 SPRING, CENTERINGSPRING, CENTERING
-
103233642 SPRING, DETENTSPRING, DETENT
-
113233060 BULLET, DETENTBULLET, DETENT
-
123233641 GEAR, SELECTOR BODYGEAR, SELECTOR BODY
-
133233640 SLIDE, HIGH/REVSLIDE, HIGH/REV
-
147546707 NUT, METRICNUT, METRIC
-
157061013 ROD END (6MM./LEFT)ROD END (6MM./LEFT)
-
167546702 NUTNUT
-
175020743 ROD, SHIFT LINKAGEROD, SHIFT LINKAGE
-
187061014 ROD END (6MM./RIGHT)ROD END (6MM./RIGHT)
-
197546701 NUTNUT
-
205132042 ROD, SHIFT LINKAGE (.31X11.75)ROD, SHIFT LINKAGE (.31X11.75)
-
213233639 SLIDE (LOW)SLIDE (LOW)
-
223233076 O-RINGO-RING
-
237512232 BOLTBOLT
-
243233644 PIN, DOWELPIN, DOWEL
-
1A1341316 GEAR SELECTOR ASSY. (INCL. 1-12, 21-24)GEAR SELECTOR ASSY. (INCL. 1-12, 21-24)
