DISTRIBUTOR HOUSING AND ROTOR для Mercury - 1150 8008665 THRU 8051949

№

Артикул

Название
1

30-20066 BEARING, DISTRIBUTOR HOUSING (UPPER)

BEARING, DISTRIBUTOR HOUSING (UPPER)
2

11-54209 NUT, ROTOR SHAFT TO DISTRIBUTOR HOUSING

NUT, ROTOR SHAFT TO DISTRIBUTOR HOUSING
3

23-53539 SLEEVE, ROTOR SHAFT

SLEEVE, ROTOR SHAFT
4

393-3736A79 HOUSING ASSEMBLY, DISTRIBUTOR

HOUSING ASSEMBLY, DISTRIBUTOR
5

53417 STRAP ASSEMBLY, Ground, DISTRIBUTOR TO CRANKCASE

STRAP ASSEMBLY, Ground, DISTRIBUTOR TO CRANKCASE
6

10-62568 SCREW, (#10-16 x .375), GROUND STRAP ATTACHING

SCREW, (#10-16 x .375), GROUND STRAP ATTACHING
7

58807A1 FLAME ARRESTOR ASSEMBLY, VENT - DISTRIBUTOR HOUSING

FLAME ARRESTOR ASSEMBLY, VENT - DISTRIBUTOR HOUSING
8

15-55853 SHIM, BALL BEARING TO DISTRIBUTOR HOUSING

SHIM, BALL BEARING TO DISTRIBUTOR HOUSING
9

30-26379 BEARING, DISTRIBUTOR HOUSING (LOWER)

BEARING, DISTRIBUTOR HOUSING (LOWER)
10

15-21148A1 SHIM SET, BALL BEARING TO SPACER

SHIM SET, BALL BEARING TO SPACER
11

23-53538 SPACER, ROTOR SHAFT

SPACER, ROTOR SHAFT
12

53-26406 RING, RETAINER - BALL BEARING TO DISTRIBUTOR HOUSING

RING, RETAINER - BALL BEARING TO DISTRIBUTOR HOUSING
13

393-4313 DISC, ROTOR

DISC, ROTOR
14

393-4312 ROTOR, DISTRIBUTOR

ROTOR, DISTRIBUTOR
15

54-60768 CLAMP, DISTRIBUTOR CAP TO DISTRIBUTOR HSG
PART OF DISTRIBUTOR CAP ASSEMBLY

CLAMP, DISTRIBUTOR CAP TO DISTRIBUTOR HSG
PART OF DISTRIBUTOR CAP ASSEMBLY
16

10-65774 SCREW, (#8-32 x 1.120), DISTRIBUTOR CAP CLAMP
PART OF DISTRIBUTOR CAP ASSEMBLY

SCREW, (#8-32 x 1.120), DISTRIBUTOR CAP CLAMP
PART OF DISTRIBUTOR CAP ASSEMBLY
17

11-26768 NUT, DISTRIBUTOR CAP CLAMP SCREW
PART OF DISTRIBUTOR CAP ASSEMBLY

NUT, DISTRIBUTOR CAP CLAMP SCREW
PART OF DISTRIBUTOR CAP ASSEMBLY
18

84-821945A5 CABLE ASSEMBLY, High Tension, CAP TO COIL
SN# USA-4112634/Australia-8027114/Canada-7047257 & Below

CABLE ASSEMBLY, High Tension, CAP TO COIL
SN# USA-4112634/Australia-8027114/Canada-7047257 & Below
18

84-821945A2 CABLE ASSEMBLY, CAP TO COIL
SN# USA-4112635/Australia-8027115/Canada-7047258 & Up

CABLE ASSEMBLY, CAP TO COIL
SN# USA-4112635/Australia-8027115/Canada-7047258 & Up
19

25-26547 GROMMET, HIGH TENSION CABLE

GROMMET, HIGH TENSION CABLE
20

332-2854T01 BOOT, HIGH TENSION CABLE TO COIL

BOOT, HIGH TENSION CABLE TO COIL
21

85-94589 SLEEVE, HIGH TENSION CABLE

SLEEVE, HIGH TENSION CABLE
22

393-4841A2 CAP ASSEMBLY, Distributor

CAP ASSEMBLY, Distributor
22

393-1293A1 BRUSH KIT

BRUSH KIT
23

58807A1 FLAME ARRESTOR ASSEMBLY, VENT - DISTRIBUTOR CAP

FLAME ARRESTOR ASSEMBLY, VENT - DISTRIBUTOR CAP
24

27-55896 GASKET, DISTRIBUTOR CAP

GASKET, DISTRIBUTOR CAP
25

33-97180Q SPARK PLUG (CHAMPION L-77V)
SN# USA-4112634/Australia-8027114/Canada-7047257 & Below

SPARK PLUG (CHAMPION L-77V)
SN# USA-4112634/Australia-8027114/Canada-7047257 & Below
25

33-97180Q SPARK PLUG (CHAMPION L-76V)
SN# USA-4112635/Australia-8027115/Canada-7047258 & Up

SPARK PLUG (CHAMPION L-76V)
SN# USA-4112635/Australia-8027115/Canada-7047258 & Up
26

84-813715A1 LEAD ASSEMBLY

LEAD ASSEMBLY
26

8M0084600 CONNECTOR, SPARK PLUG LEAD

CONNECTOR, SPARK PLUG LEAD
-

36549A1 MARKER KIT

MARKER KIT
27

85-63709A1 PROTECTOR, SPARK PLUG LEAD

PROTECTOR, SPARK PLUG LEAD
28

85-94589 SLEEVE, SPARK PLUG LEAD TO DISTRIBUTOR

SLEEVE, SPARK PLUG LEAD TO DISTRIBUTOR
28A

23-622381 SLEEVE, SPARK PLUG LEAD (7")

SLEEVE, SPARK PLUG LEAD (7")
29

25-26547 GROMMET, SPARK PLUG LEADS

GROMMET, SPARK PLUG LEADS
30

45409 RETAINER, Wire, HIGH TENSION LEADS

RETAINER, Wire, HIGH TENSION LEADS
31

45392 BRACKET, FRONT - WIRE RETAINER

BRACKET, FRONT - WIRE RETAINER
32

47398 BRACKET, REAR - WIRE RETAINER

BRACKET, REAR - WIRE RETAINER
33

10-62568 SCREW, (#10-16 x .375), FRONT AND REAR BRACKET ATTACHING

SCREW, (#10-16 x .375), FRONT AND REAR BRACKET ATTACHING
34

45391 SPACER, RUBBER - HIGH TENSION LEADS

SPACER, RUBBER - HIGH TENSION LEADS
