REAR BRAKE CONTROL для Ktm 450 RALLY FACTORY REPLICA - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    76413150044 FOOT BRAKE LEVER CPL.
    FOOT BRAKE LEVER CPL.
  • 2
    0625006087 GROOVED BALL BEAR. 608 2RS C3
    GROOVED BALL BEAR. 608 2RS C3
  • 3
    0472022100 CIRCLIP DIN0472-22X1
    CIRCLIP DIN0472-22X1
  • 4
    56509064100 SELF LOCKING NUT M6
    SELF LOCKING NUT M6
  • 5
    76413050030 BOLT
    BOLT
  • 6
    0015050123 HH COLLAR SCREW M 5X12
    HH COLLAR SCREW M 5X12
  • 7
    76413050010 ARRESTOR
    ARRESTOR
  • 8
    54603069000 SWIVEL HEAD M6 FOOT BRAKE LEV.
    SWIVEL HEAD M6 FOOT BRAKE LEV.
  • 9
    76413050020 THREADED BOLT
    THREADED BOLT
  • 11
    76213051010 BRAKE LEVER PEDAL LARGE RALLY
    BRAKE LEVER PEDAL LARGE RALLY
  • 12
    76213060000 FOOT BRAKE CYLINDER REAR
    FOOT BRAKE CYLINDER REAR
  • 13
    54813020100 HOLLOW SCREW BLACK M10X1X19
    HOLLOW SCREW BLACK M10X1X19
  • 14
    54513150000 REPAIR KIT PISTON 13MM
    REPAIR KIT PISTON 13MM
  • 15
    0025060256 HH COLLAR SCREW M6X25
    HH COLLAR SCREW M6X25
  • 16
    76413050110 STOP PIN
    STOP PIN
  • 17
    76203068000 PUSH ROD MAIN BRAKE CYLINDER
    PUSH ROD MAIN BRAKE CYLINDER
  • 18
    0934060003 HEXAGON NUT DIN0934-M 6
    HEXAGON NUT DIN0934-M 6
  • 21
    0985060003 SELF LOCK. NUT DIN0985-M 6
    SELF LOCK. NUT DIN0985-M 6
  • 22
    76213070000 BRAKE HOSE REAR
    BRAKE HOSE REAR
  • 23
    0603100141 COPPER GASKET DIN7603-10X14X1
    COPPER GASKET DIN7603-10X14X1
  • 24
    0125060003 WASHER DIN0125-A 6,4
    WASHER DIN0125-A 6,4
  • 25
    54513030044 BRAKE FLUID RESERVOIR
    BRAKE FLUID RESERVOIR
  • 26
    0024060106 HH COLLAR SCREW M6X10
    HH COLLAR SCREW M6X10
  • 28
    58007017000 YDNAC CLAMP 10101 (10,4MM)
    YDNAC CLAMP 10101 (10,4MM)
  • 29
    76213061000 HOSE FOR BRAKE FLUID RESERVOIR
    HOSE FOR BRAKE FLUID RESERVOIR
  • 30
    61234014000 RETURNSPRING 2MM
    RETURNSPRING 2MM
  • 31
    00062030000 BRAKE FLUID DOT5.1 0,25L
    BRAKE FLUID DOT5.1 0,25L
  • 32
    0025050256 HH COLLAR SCREW M5X25 ISA30
    HH COLLAR SCREW M5X25 ISA30
  • 33
    0934050003 HEXAGON NUT DIN0934-M 5
    HEXAGON NUT DIN0934-M 5
