HANDLEBAR для Kawasaki W650 - 2001 года выпуска

  • №
    Артикул
    Название
  • 120
    120S0625 BOLT, SOCKET, 6X25 (BLACK)
    BOLT, SOCKET, 6X25 (BLACK)
  • 220
    220C0520 SCREW, PAN, CROS
    SCREW, PAN, CROS
  • 220A
    220C0535 SCREW, PAN, CROS
    SCREW, PAN, CROS
  • 220B
    220C0540 SCREW, PAN, CROS
    SCREW, PAN, CROS
  • 221
    221B0320 SCREW, CSK, CROS, 3X20
    SCREW, CSK, CROS, 3X20
  • 13280
    13280-1137 HOLDER, CLUTCH LEVER
    HOLDER, CLUTCH LEVER
  • 13280A
    13280-1138 HOLDER, CLUTCH LEVER
    HOLDER, CLUTCH LEVER
  • 27010
    27010-1268 SWITCH, CLUTCH
    SWITCH, CLUTCH
  • 46003
    46003-1545 HANDLE
    HANDLE
  • 46012
    46012-1294 HOLDER, HANDLE, UPPER
    HOLDER, HANDLE, UPPER
  • 46019
    46019-1110 GRIP, ASSY., THROTTLE
    GRIP, ASSY., THROTTLE
  • 46055
    46055-003 SCREW, CABLE ADJUST, 8MM
    SCREW, CABLE ADJUST, 8MM
  • 46056
    46056-005 NUT, CABLE ADJUST LOCK, 8MM
    NUT, CABLE ADJUST LOCK, 8MM
  • 46075
    46075-1175 GRIP (LEFT)
    GRIP (LEFT)
  • 46076
    46076-1223 LEVER, ASSY., GRIP, CLUTCH
    LEVER, ASSY., GRIP, CLUTCH
  • 46091
    46091-1778 HOUSING, ASSY., CONTROL (RIGHT)
    HOUSING, ASSY., CONTROL (RIGHT)
  • 46091A
    46091-1779 HOUSING, ASSY., CONTROL (LEFT)
    HOUSING, ASSY., CONTROL (LEFT)
  • 46092
    46092-1209 LEVER, GRIP, CLUTCH
    LEVER, GRIP, CLUTCH
  • 56001
    56001-1451 MIRROR, ASSY. (LEFT)
    MIRROR, ASSY. (LEFT)
  • 56001A
    56001-1452 MIRROR, ASSY. (RIGHT)
    MIRROR, ASSY. (RIGHT)
  • 92015
    92015-1191 NUT, LOCK, 6MM (BLACK)
    NUT, LOCK, 6MM (BLACK)
  • 92037
    92037-1163 CLAMP, SPEED, L=58
    CLAMP, SPEED, L=58
  • 92143
    92143-1351 COLLAR
    COLLAR
  • 92151
    92151-1402 BOLT, FLANGED, 8X35
    BOLT, FLANGED, 8X35
  • 92151A
    92151-1523 BOLT
    BOLT
  • 92171
    92171-1146 CLAMP, HANDLE SWITCH HARNESS (LEFT)
    CLAMP, HANDLE SWITCH HARNESS (LEFT)
  • 92171A
    92171-1148 CLAMP, HANDLE SWITCH HARNESS (RIGHT)
    CLAMP, HANDLE SWITCH HARNESS (RIGHT)
