GEAR CHANGE DRUM W/ SHIFT FORK(S) для Kawasaki W650 - 2001 года выпуска`
-
№АртикулНазвание
-
610610A0408 ROLLER, 4X8ROLLER, 4X8
-
1314013140-1282 FORK, SHIFT, INPUT 3RDFORK, SHIFT, INPUT 3RD
-
13140A13140-1283 FORK, SHIFT, OUTPUT 4TH AND TOPFORK, SHIFT, OUTPUT 4TH AND TOP
-
1314513145-1083 CAM, CHANGE DRUMCAM, CHANGE DRUM
-
1323913239-1205 DRUM, ASSY., CHANGEDRUM, ASSY., CHANGE
-
1401414014-1141 PLATE, POSITIONPLATE, POSITION
-
4904749047-1102 ROD, SHIFTROD, SHIFT
-
9200292002-1796 BOLT, SOCKET, 6X12BOLT, SOCKET, 6X12
-
9200992009-1360 SCREW, 6X16SCREW, 6X16
-
9204392043-1518 PIN, 5X21.8PIN, 5X21.8
-
92043A92043-1523 PINPIN
-
9204592045-1045 BEARING, BALL, 16005 (NTN)BEARING, BALL, 16005 (NTN)
-
9214492144-1245 SPRINGSPRING
-
9215092150-1958 BOLT, SOCKET, 6X40BOLT, SOCKET, 6X40
