SUSPENSION - REAR для Polaris 600 IQ RACER AND EURO (S08MX6JS/JE) - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    5413403 TRACK-121''X14.75''X1.75'', SNO-XT
    TRACK-121''X14.75''X1.75'', SNO-XT
  • 1
    5250304 CLIP-GUIDE, SOUCY TRACK
    CLIP-GUIDE, SOUCY TRACK
  • 1
    5250313 CLIP-FLAT, SOUCY, 04-150-20-1000
    CLIP-FLAT, SOUCY, 04-150-20-1000
  • 2
    7547263 NUT-3/8-24 NYLOK
    NUT-3/8-24 NYLOK
  • 3
    7555918 BUSHING
    BUSHING
  • 4
    1590426 ASM-WHEEL 6.38 OD PLAIN, RACE
    ASM-WHEEL 6.38 OD PLAIN, RACE
  • 5
    5333283 SPACER, IDLER, CTRIGHT HAND
    SPACER, IDLER, CTRIGHT HAND
  • 6
    7517731 BOLT, 3/8-16X1.25
    BOLT, 3/8-16X1.25
  • 7
    7556130 WASHER-.406X1.25X.125
    WASHER-.406X1.25X.125
  • 8
    5432535 SPACER, IDLER
    SPACER, IDLER
  • 9
    5132066 SHAFT-IDLER, .784X13.22, 7075
    SHAFT-IDLER, .784X13.22, 7075
  • 10
    7555893 WASHER, FLAT
    WASHER, FLAT
  • 11
    5334026 SHAFT-.740X.390X8.490, ANODIZE
    SHAFT-.740X.390X8.490, ANODIZE
  • 12
    1541713-067 WELD-REAR PIVOT ARM, 4.25, BLACK
    WELD-REAR PIVOT ARM, 4.25, BLACK
  • 13
    1541711-067 WELD-MNT, SHOCK, BLACK
    WELD-MNT, SHOCK, BLACK
  • 14
    5133233 BUSHING-.378X.616X1.720
    BUSHING-.378X.616X1.720
  • 15
    1542055-067 WELD-SHOCK PIVOT ARM, 3.50, BLACK
    WELD-SHOCK PIVOT ARM, 3.50, BLACK
  • 16
    7080424 FITTING, LUBRICATION
    FITTING, LUBRICATION
  • 17
    5135352 SPACER-BOGIE WHEEL PRESS
    SPACER-BOGIE WHEEL PRESS
  • 18
    5133232 SHAFT-.750X.390X8.665, AL
    SHAFT-.750X.390X8.665, AL
  • 19
    7556301 BUSHING
    BUSHING
  • 20
    5333906 SLEEVE, .385X.560X1.72
    SLEEVE, .385X.560X1.72
  • 21
    7515417 SCREW
    SCREW
  • 22
    5134078 SHAFT-C'BORE, .688X8.665, 2045
    SHAFT-C'BORE, .688X8.665, 2045
  • 23
    7556188 WASHER-FLEFT HAND390X.750X.065-Y
    WASHER-FLEFT HAND390X.750X.065-Y
  • 24
    7518005 SCR-3/8-16X1.50-HX/CP-GR5-P80Y
    SCR-3/8-16X1.50-HX/CP-GR5-P80Y
  • 25
    1541642 ASM-WHEEL, 5.62 W/HOLE
    ASM-WHEEL, 5.62 W/HOLE
  • 26
    7517921 SCR-3/8-24X9.875, HX/LP, GR8-Y
    SCR-3/8-24X9.875, HX/LP, GR8-Y
  • 27
    7517247 SCREW
    SCREW
  • 28
    7515317 BOLT
    BOLT
  • 29
    7515346 SCREW
    SCREW
  • 30
    7556179 WASHER-SPRING, CON 5/16X.090-Y
    WASHER-SPRING, CON 5/16X.090-Y
  • 31
    1590317 ASM-WHEEL, BOGIE, PLAIN, 5.62
    ASM-WHEEL, BOGIE, PLAIN, 5.62
  • 31
    3514303 BEARING #6205
    BEARING #6205
  • 31
    7718407 RING-RETAINING
    RING-RETAINING
  • 32
    5631065 BLOCK-WHEEL MOUNT, LWT
    BLOCK-WHEEL MOUNT, LWT
  • 33
    7542324 NUT, NYLOK
    NUT, NYLOK
  • 34
    5134796 SHAFT-COUPLER BLOCK
    SHAFT-COUPLER BLOCK
  • 35
    7515551 SCREW
    SCREW
  • 36
    5413272 BUMPER-PIVOT, LAMINATE
    BUMPER-PIVOT, LAMINATE
