SUSPENSION - REAR TRACK для Polaris 440 PRO X (S02NX4CS) - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    7512014 SCREW
    SCREW
  • 2
    7552615 WASHER, LOCK
    WASHER, LOCK
  • 3
    7555783 WASHER
    WASHER
  • 4
    7542439 NUT, NYLOCK
    NUT, NYLOCK
  • 5
    7555806 WASHER
    WASHER
  • 6
    7515319 BOLT
    BOLT
  • 7
    7558402 WASHER STEEL
    WASHER STEEL
  • 8
    5432535 SPACER, IDLER
    SPACER, IDLER
  • 9
    7555918 BUSHING
    BUSHING
  • 10
    1594087 WHEEL ASSY. PLAIN (6.38 O.D.)
    WHEEL ASSY. PLAIN (6.38 O.D.)
  • 10
    7710444 RING, RETAINING
    RING, RETAINING
  • 10
    3514012 BEARING
    BEARING
  • 11
    5132066 SHAFT, IDLER (.784X13.22, 7075)
    SHAFT, IDLER (.784X13.22, 7075)
  • 12
    5333283 SPACER, IDLER (CTR.)
    SPACER, IDLER (CTR.)
  • 13
    7556130 WASHER (.406X1.25X.125)
    WASHER (.406X1.25X.125)
  • 14
    7517731 BOLT (3/8, 16X1.25)
    BOLT (3/8, 16X1.25)
  • 15
    7517921 SCREW
    SCREW
  • 16
    7552603 WASHER
    WASHER
  • 17
    7517247 SCREW
    SCREW
  • 18
    5412197 TRACK (121'', 1 3/8 SHOCKWAVE)
    TRACK (121'', 1 3/8 SHOCKWAVE)
  • 18
    5222840 CLIP, GUIDE CAMOPLAST
    CLIP, GUIDE CAMOPLAST
  • 19
    5020723 SHAFT, PIVOT ARM
    SHAFT, PIVOT ARM
  • 20
    5132997 CLAMP, HOSE ARVIN
    CLAMP, HOSE ARVIN
  • 21
    1541642 WHEEL ASSY. (5.62 W/HOLE)
    WHEEL ASSY. (5.62 W/HOLE)
  • 22
    7556301 MACHINERY BUSHING
    MACHINERY BUSHING
  • 23
    5133232 SHAFT (.750X.390X8.665, AL)
    SHAFT (.750X.390X8.665, AL)
  • 24
    7515417 BOLT
    BOLT
  • 25
    7080424 FITTING, LUBE
    FITTING, LUBE
  • 26
    5133233 BUSHING (.378X.616X1.720)
    BUSHING (.378X.616X1.720)
  • 27
    1541638-067 WELD, SHOCK PIVOT ARM (3.50, BLACK)
    WELD, SHOCK PIVOT ARM (3.50, BLACK)
  • 28
    1541711-067 WELD, SHOCK MOUNT (BLACK)
    WELD, SHOCK MOUNT (BLACK)
  • 29
    7542324 NUT
    NUT
  • 30
    5132832 CLAMP, RESERVIOR (M10)
    CLAMP, RESERVIOR (M10)
  • 31
    7555893 WASHER
    WASHER
  • 32
    1541713-067 WELD, REAR PIVOT ARM (4.25, BLACK)
    WELD, REAR PIVOT ARM (4.25, BLACK)
  • 33
    5334026 SHAFT (.740X.390X8.490, ANODIZE)
    SHAFT (.740X.390X8.490, ANODIZE)
