SWING ARM/ REAR/ GEARCASE MOUNTING для Polaris MAGNUM 500 4X4 (A03CD50FB) - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    5412022 O-RING
    O-RING
  • 2
    5133360 HUB, WHEEL AWD (MACH)
    HUB, WHEEL AWD (MACH)
  • 3
    7515513 STUD
    STUD
  • 4
    5244882 DISC, BRAKE (8.125 X .188) (REAR)
    DISC, BRAKE (8.125 X .188) (REAR)
  • 5
    7515481 BOLT
    BOLT
  • 5
    7552603 WASHER, SPRING LOCK
    WASHER, SPRING LOCK
  • 6
    7517604 BOLT
    BOLT
  • 7
    7555721 WASHER
    WASHER
  • 8
    7547065 NUT (1/2-20) NYLOK
    NUT (1/2-20) NYLOK
  • 9
    5133387 NUT, JAM SWINGARM PIVOT
    NUT, JAM SWINGARM PIVOT
  • 10
    5133388 PIVOT, THREADED SWINGARM (LEFT)
    PIVOT, THREADED SWINGARM (LEFT)
  • 11
    3514399 BEARING, TAPERED ROLLER CONE
    BEARING, TAPERED ROLLER CONE
  • 12
    3514398 BEARING, TAPERED ROLLER CUP
    BEARING, TAPERED ROLLER CUP
  • 13
    5812447 FOAM, SWINGARM PIVOT
    FOAM, SWINGARM PIVOT
  • 14
    1541820 SWINGARM (3/4'' PIVOT) ASSY. [INCL. 12]
    SWINGARM (3/4'' PIVOT) ASSY. [INCL. 12]
  • 15
    5412202 O-RING
    O-RING
  • 16
    1380202 ASSY., PROP SHAFT (REAR)
    ASSY., PROP SHAFT (REAR)
  • 17
    7661913 PIN, SPRING
    PIN, SPRING
  • 18
    5133389 PIVOT, THREADED SWINGARM (RIGHT)
    PIVOT, THREADED SWINGARM (RIGHT)
  • 19
    7553201 LOCK WASHER
    LOCK WASHER
  • 20
    7517585 BOLT (1/2-13 X 1 1/4 HXHD GR5-Z)
    BOLT (1/2-13 X 1 1/4 HXHD GR5-Z)
  • 21
    5133626 AXLE (REAR)
    AXLE (REAR)
  • 22
    7517612 SCREW
    SCREW
  • 23
    5411531 O-RING
    O-RING
  • 25
    1012881 SKID PLATE (REAR)
    SKID PLATE (REAR)
  • 25
    5242851-067 PLATE, SKID HOUSING (REAR/ BLACK)
    PLATE, SKID HOUSING (REAR/ BLACK)
  • 25
    5811716 PAD, RUBBER
    PAD, RUBBER
  • 26
    5132698 COLLAR, AXLE LOCK
    COLLAR, AXLE LOCK
  • 27
    5411707 O-RING
    O-RING
  • 28
    7170910 DECAL, HITCH 1000 LBS.
    DECAL, HITCH 1000 LBS.
  • 29
    5245050 CLAMP, BRAKE LINE (REAR)
    CLAMP, BRAKE LINE (REAR)
  • 30
    7512017 SCREW
    SCREW
  • 31
    1013264-067 AXLE,TUBE VL (BLACK/ LEFT)
    AXLE,TUBE VL (BLACK/ LEFT)
  • 32
    3514342 BEARING, HUBSTRUT VISCO
    BEARING, HUBSTRUT VISCO
  • 33
    7710507 RING, RETAINER (.,2.500 INTERNAL)
    RING, RETAINER (.,2.500 INTERNAL)
  • 34
    7512325 BOLT
    BOLT
