STARTER MOTOR ASSEMBLY, COMPLETE (B-50-69863A1) для Mercruiser - 140 GM 181 I/L4 1979-1982 5157669 THRU 6229717

  • №
    Артикул
    Название
  • -
    50-8M0090697 STARTER MOTOR ASSEMBLY, COMPLETE (DELCO REMY #1108756)
    STARTER MOTOR ASSEMBLY, COMPLETE (DELCO REMY #1108756)
  • -
    50-8M0090697 STARTER MOTOR ASSEMBLY, COMPLETE (DELCO REMY #118755)
    STARTER MOTOR ASSEMBLY, COMPLETE (DELCO REMY #118755)
  • 1
    71696 HOUSING, DRIVE END
    HOUSING, DRIVE END
  • 2
    23-33369 BUSHING, DRIVE END HOUSING
    BUSHING, DRIVE END HOUSING
  • 3
    23-809457 COLLAR, THRUST - DRIVE END HOUSING
    COLLAR, THRUST - DRIVE END HOUSING
  • 4
    53-33290 RING, RETAINING - PINION STOP COLLAR
    RING, RETAINING - PINION STOP COLLAR
  • 5
    33291 COLLAR, PINION STOP - DRIVE END HOUSING
    COLLAR, PINION STOP - DRIVE END HOUSING
  • 6
    79205T DRIVE ASSEMBLY, CLUTCH - ARMATURE
    DRIVE ASSEMBLY, CLUTCH - ARMATURE
  • 7
    23-33369 BUSHING, GEAR END - CLUTCH DRIVE (1 9/16")
    BUSHING, GEAR END - CLUTCH DRIVE (1 9/16")
  • 8
    24-33368 SPRING, CLUTCH DRIVE
    SPRING, CLUTCH DRIVE
  • 9
    N.S.S. COLLAR, CLUTCH DRIVE (DELCO REMY #1904443)
    COLLAR, CLUTCH DRIVE (DELCO REMY #1904443)
  • 10
    33367 LOCKSIRE, COLLAR AND SPRING RETAINING
    LOCKSIRE, COLLAR AND SPRING RETAINING
  • 11
    N.S.S. PLATE, BEARING (DELCO REMY #1956939)
    PLATE, BEARING (DELCO REMY #1956939)
  • 12
    23-71694 BUSHING, BEARING PLATE
    BUSHING, BEARING PLATE
  • 13
    12-68614 WASHER, BEARING PLATE
    WASHER, BEARING PLATE
  • 14
    10-68612 SCREW, BEARING PLATE ATTACHING
    SCREW, BEARING PLATE ATTACHING
  • 15
    13-68611 LOCKWASHER, BEARING PLATE SCREW
    LOCKWASHER, BEARING PLATE SCREW
  • 16
    71693 ARMATURE
    ARMATURE
  • 17
    N.S.S. SHOE, POLE - FIELD COIL (DELCO REMY #1931129)
    SHOE, POLE - FIELD COIL (DELCO REMY #1931129)
  • 18
    10-60684 SCREW, POLE SHOE TO FIELD COIL
    SCREW, POLE SHOE TO FIELD COIL
  • 19
    33293 INSULATION, FIELD COIL
    INSULATION, FIELD COIL
  • 20
    25-45534 GROMMET, FIELD COIL - FIELD FRAME
    GROMMET, FIELD COIL - FIELD FRAME
  • 21
    46891 FIELD COIL ASSEMBLY
    FIELD COIL ASSEMBLY
  • 21
    71697 FIELD COIL ASSEMBLY
    FIELD COIL ASSEMBLY
  • 22
    N.S.S. COIL, SHUNT - FIELD COIL (DELCO REMY #1935131)
    COIL, SHUNT - FIELD COIL (DELCO REMY #1935131)
  • 23
    12-33258 WASHER, LEATHER - COMMUTATOR END FRAME
    WASHER, LEATHER - COMMUTATOR END FRAME
  • 24
    79211 FRAME, COMMUTATOR END - LOWER
    FRAME, COMMUTATOR END - LOWER
  • 25
    10-33296 BOLT, THRU - COMMUTATOR END TO DRIVE END HOUSING
    BOLT, THRU - COMMUTATOR END TO DRIVE END HOUSING
  • 25
    10-33286 BOLT, THRU - COMMUATOR END TO DRIVE END HOUSING
    BOLT, THRU - COMMUATOR END TO DRIVE END HOUSING
  • 26
    33284 HOLDER, INSULATED - FIELD FRAME BRUSH GROUND
    HOLDER, INSULATED - FIELD FRAME BRUSH GROUND
  • 27
    33283 HOLDER, FIELD FRAME BUSH GROUND
    HOLDER, FIELD FRAME BUSH GROUND
  • 28
    33270 BRUSH, FIELD FRAME
    BRUSH, FIELD FRAME
  • 29
    10-52904 SCREW, BRUSH LEAD TO FIELD FRAME BRUSH (8-18 X 5/8")
    SCREW, BRUSH LEAD TO FIELD FRAME BRUSH (8-18 X 5/8")
  • 29
    10-60685 SCREW, RUCH LEAD TO FIELD FRAME BRUSH
    SCREW, RUCH LEAD TO FIELD FRAME BRUSH
  • 30
    33294 SUPPORT PACKAGE, GROUND AND INSULATED HOLDERS
    SUPPORT PACKAGE, GROUND AND INSULATED HOLDERS
  • 31
    N.S.S. PIN, GROUND AND INSULATION HOLDER TO SUPPORT (DELCO REMY)
    PIN, GROUND AND INSULATION HOLDER TO SUPPORT (DELCO REMY)
  • 32
    33294 LEAD, FIELD FRAME BRUSH
    LEAD, FIELD FRAME BRUSH
  • 33
    N.S.S. SCREW, SUPPORT TO FIELD FRAME (DELCO REMY #274738)
    SCREW, SUPPORT TO FIELD FRAME (DELCO REMY #274738)
  • 34
    13-26996 LOCKWASHER, SUPPORT SCREW
    LOCKWASHER, SUPPORT SCREW
  • 35
    11-30968 NUT, SUPPORT SCREW
    NUT, SUPPORT SCREW
  • 36
    24-33285 SPRING, FIELD FRAME BRUSH
    SPRING, FIELD FRAME BRUSH
  • 37
    17-33257 PIN, DOWEL - FIELD BRAME TO DRIVE END HOUSNG
    PIN, DOWEL - FIELD BRAME TO DRIVE END HOUSNG
  • 38
    71698 LEVER, SHIFT - DRIVE END HOUSING
    LEVER, SHIFT - DRIVE END HOUSING
  • 39
    33310 SHAFT, SHIFT LEVER TO DRIVE END HOUSING
    SHAFT, SHIFT LEVER TO DRIVE END HOUSING
  • 40
    53-33354 RING, RETAINING - SHIFT LEVER SHAFT
    RING, RETAINING - SHIFT LEVER SHAFT
  • 41
    33317 PLUNGER, SHIFT LEVER - SOLENOID SWITCH
    PLUNGER, SHIFT LEVER - SOLENOID SWITCH
  • 42
    17-24198 PIN, PLUNGER TO SHIFT LEVER
    PIN, PLUNGER TO SHIFT LEVER
  • 43
    24-46889 SPRING, PLUNGER RETURNE - SOLENOID SWITCH
    SPRING, PLUNGER RETURNE - SOLENOID SWITCH
  • 44
    10-28713 SCREW, SOLENOID SWITCH TO DRIVE END HOUSING
    SCREW, SOLENOID SWITCH TO DRIVE END HOUSING
  • 45
    33261 SOLENOIDD SWITCH ASSEMBLY
    SOLENOIDD SWITCH ASSEMBLY
  • 45
    33261 SOLENOID SWITCH ASSEMBLY
    SOLENOID SWITCH ASSEMBLY
  • 46
    33261 CONTRACT AND PUSH ROD ASSEMBLY
    CONTRACT AND PUSH ROD ASSEMBLY
  • 47
    24-33265 SPRING, CONTRACT AND PUSH ROD TENSION
    SPRING, CONTRACT AND PUSH ROD TENSION
  • 48
    N.S.S. COVER, SOLENOID SWITCH (DELCO REMY #1935167)
    COVER, SOLENOID SWITCH (DELCO REMY #1935167)
  • 48
    N.S.S. COVER, SOLENOID SWITCH (DELCO REMY #1963525)
    COVER, SOLENOID SWITCH (DELCO REMY #1963525)
  • 49
    16-33304 STUD, RESISTOR TERMINAL (10-32)
    STUD, RESISTOR TERMINAL (10-32)
  • 50
    33305 CONCTRACT, RESISTOR TERMINAL STUD
    CONCTRACT, RESISTOR TERMINAL STUD
  • 51
    13-26996 LOCKWASHER, RESISTOR TERMINAL STUD (#10)
    LOCKWASHER, RESISTOR TERMINAL STUD (#10)
  • 52
    11-68219 NUT, RESISTOR TERMINAL STUD (10-32)
    NUT, RESISTOR TERMINAL STUD (10-32)
  • 53
    16-33299 STUD, MOTOR TERMINAL (3/8-16)
    STUD, MOTOR TERMINAL (3/8-16)
  • 54
    16-45536 STUD, BATTERY TERMINAL (3/8-16)
    STUD, BATTERY TERMINAL (3/8-16)
  • 55
    12-33289 WASHER, BATTERY AND MOTOR TERMINAL STUD (3/8")
    WASHER, BATTERY AND MOTOR TERMINAL STUD (3/8")
  • 56
    11-32219 NUT, BATTERY AND MOTOR TERMINAL STUD (3/8-16)
    NUT, BATTERY AND MOTOR TERMINAL STUD (3/8-16)
  • 57
    13-35048 LOCKWASHER, BATTERY TERMINAL STUD (3/8")
    LOCKWASHER, BATTERY TERMINAL STUD (3/8")
  • 58
    11-32219 NUT, BATTERY TERMINAL STUD (3/8-16)
    NUT, BATTERY TERMINAL STUD (3/8-16)
  • 59
    16-33262 STUD, SWITCH TERMINAL (8-32)
    STUD, SWITCH TERMINAL (8-32)
  • 60
    54-33307 CLIP, SWITCH TERMINAL STUD
    CLIP, SWITCH TERMINAL STUD
  • 61
    12-33279 WASHER, PLASTIC - SWITCH TERMINAL STUD (#8)
    WASHER, PLASTIC - SWITCH TERMINAL STUD (#8)
  • 62
    11-21923T NUT, SWITCH TERMINAL STUD (8-32)
    NUT, SWITCH TERMINAL STUD (8-32)
  • 63
    13-26995 LOCKWASHER, SWITCH TERMINAL STUD (#8)
    LOCKWASHER, SWITCH TERMINAL STUD (#8)
  • 64
    10-33248 SCREW, COVER TO SOLENOID SWITCH (7/16")
    SCREW, COVER TO SOLENOID SWITCH (7/16")
  • 65
    12-33279 WASHER, PLASTIC - COVER SCREW
    WASHER, PLASTIC - COVER SCREW
  • 66
    10-48266 SCREW, FIELD COIL LEAD TO SOLENOID SWITCH (7/16")
    SCREW, FIELD COIL LEAD TO SOLENOID SWITCH (7/16")
  • 66
    10-45546 SCREW, FIELD COIL LEAD TO SOLENOID SWITCH (1")
    SCREW, FIELD COIL LEAD TO SOLENOID SWITCH (1")
  • 67
    13-26995 LOCKWASHER, FIELD COIL LEAD SCREW
    LOCKWASHER, FIELD COIL LEAD SCREW
  • 68
    N.S.S. CONNECTOR, FIELD COIL LEAD SCREW (DELCO REMY #1963519)
    CONNECTOR, FIELD COIL LEAD SCREW (DELCO REMY #1963519)
