SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat ZR 6000 R SX (GREEN) [S2015ACDPRUSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    4718-582 PANEL, SIDE W/DECALS - RIGHT - (TEAM ARCTIC GREEN) (INC. 2-14)
    PANEL, SIDE W/DECALS - RIGHT - (TEAM ARCTIC GREEN) (INC. 2-14)
  • 2
    4718-608 ...PANEL, SIDE W/O DECALS - RIGHT - (TEAM ARCTIC GREEN) (INC. 3-9)
    ...PANEL, SIDE W/O DECALS - RIGHT - (TEAM ARCTIC GREEN) (INC. 3-9)
  • 3
    9611-498 ......DECAL, WARNING (FRENCH)
    ......DECAL, WARNING (FRENCH)
  • 4
    0617-736 ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT
    ......FOAM, SIDE PANEL - UPPER FRONT - RIGHT
  • 5
    0617-634 ......FOAM, SIDE PANEL - LOWER REAR - RIGHT
    ......FOAM, SIDE PANEL - LOWER REAR - RIGHT
  • 6
    0617-632 ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT
    ......FOAM, SIDE PANEL - LOWER FRONT - RIGHT
  • 7
    0617-696 ......FOAM, SIDE PANEL - UPPER CENTER - RIGHT
    ......FOAM, SIDE PANEL - UPPER CENTER - RIGHT
  • 8
    0617-700 ......FOAM, SIDE PANEL - UPPER REAR - RIGHT
    ......FOAM, SIDE PANEL - UPPER REAR - RIGHT
  • 9
    6606-414 ......FOIL, PROTECTIVE
    ......FOIL, PROTECTIVE
  • 10
    0621-755 ...DECAL, "ARCTIC CAT"
    ...DECAL, "ARCTIC CAT"
  • 11
    2621-376 ...DECAL, SIDE PANEL - UPPER - RIGHT
    ...DECAL, SIDE PANEL - UPPER - RIGHT
  • 12
    2621-374 ...DECAL, SIDE PANEL - CENTER - RIGHT
    ...DECAL, SIDE PANEL - CENTER - RIGHT
  • 13
    2621-370 ...DECAL, SIDE PANEL - LOWER FRONT - RIGHT
    ...DECAL, SIDE PANEL - LOWER FRONT - RIGHT
  • 14
    2621-372 ...DECAL, SIDE PANEL - LOWER REAR - RIGHT
    ...DECAL, SIDE PANEL - LOWER REAR - RIGHT
  • 15
    4718-583 PANEL, SIDE W/DECALS - LEFT - (TEAM ARCTIC GREEN) (INC. 16-27)
    PANEL, SIDE W/DECALS - LEFT - (TEAM ARCTIC GREEN) (INC. 16-27)
  • 16
    4718-609 ...PANEL, SIDE W/O DECALS - LEFT - (TEAM ARCTIC GREEN) (INC. 17-23)
    ...PANEL, SIDE W/O DECALS - LEFT - (TEAM ARCTIC GREEN) (INC. 17-23)
  • 17
    9611-499 ......DECAL, WARNING (ENGLISH)
    ......DECAL, WARNING (ENGLISH)
  • 18
    6606-466 ......FOIL, PROTECTIVE
    ......FOIL, PROTECTIVE
  • 19
    0617-737 ......FOAM, SIDE PANEL - UPPER FRONT - LEFT
    ......FOAM, SIDE PANEL - UPPER FRONT - LEFT
  • 20
    0617-635 ......FOAM, SIDE PANEL - LOWER REAR - LEFT
    ......FOAM, SIDE PANEL - LOWER REAR - LEFT
  • 21
    0617-633 ......FOAM, SIDE PANEL - LOWER FRONT - LEFT
    ......FOAM, SIDE PANEL - LOWER FRONT - LEFT
  • 22
    0617-697 ......FOAM, SIDE PANEL - UPPER CENTER - LEFT
    ......FOAM, SIDE PANEL - UPPER CENTER - LEFT
  • 23
    0617-735 ......FOAM, SIDE PANEL - UPPER REAR - LEFT
    ......FOAM, SIDE PANEL - UPPER REAR - LEFT
  • 24
    2621-377 ...DECAL, SIDE PANEL - UPPER - LEFT
    ...DECAL, SIDE PANEL - UPPER - LEFT
  • 25
    2621-375 ...DECAL, SIDE PANEL - CENTER - LEFT
    ...DECAL, SIDE PANEL - CENTER - LEFT
  • 26
    2621-371 ...DECAL, SIDE PANEL - LOWER FRONT - LEFT
    ...DECAL, SIDE PANEL - LOWER FRONT - LEFT
  • 27
    2621-373 ...DECAL, SIDE PANEL - LOWER REAR - LEFT
    ...DECAL, SIDE PANEL - LOWER REAR - LEFT
  • 28
    2623-003 PIN, RETAINING
    PIN, RETAINING
  • 29
    2623-056 RETAINER
    RETAINER
  • 30
    8050-127 WASHER
    WASHER
  • 31
    8060-486 RIVET
    RIVET
  • 32
    0607-447 CABLE
    CABLE
  • 33
    0605-283 CLIP, HAIRPIN
    CLIP, HAIRPIN
  • 34
    8061-708 RIVET
    RIVET
  • 35
    6606-943 SADDLEBAG
    SADDLEBAG
  • 36
    0123-802 WASHER
    WASHER
  • 37
    0607-659 STRAP, HOLD-DOWN
    STRAP, HOLD-DOWN
  • 38
    4718-584 PLATE, SKID W/DECALS - RIGHT (INC. 39-46)
    PLATE, SKID W/DECALS - RIGHT (INC. 39-46)
  • 39
    3718-784 ...PLATE, SKID W/O DECALS - RIGHT (BLACK) (INC. 40-44)
    ...PLATE, SKID W/O DECALS - RIGHT (BLACK) (INC. 40-44)
  • 40
    0617-640 ......FOAM, SKID PLATE - UPPER REAR - RIGHT
    ......FOAM, SKID PLATE - UPPER REAR - RIGHT
  • 41
    0617-638 ......FOAM, SKID PLATE - CENTER FRONT - RIGHT
    ......FOAM, SKID PLATE - CENTER FRONT - RIGHT
  • 42
    0617-636 ......FOAM, SKID PLATE - UPPER FRONT - RIGHT
    ......FOAM, SKID PLATE - UPPER FRONT - RIGHT
  • 43
    6606-352 ......FOIL, PROTECTIVE - LOWER SKID - RIGHT
    ......FOIL, PROTECTIVE - LOWER SKID - RIGHT
  • 44
    6606-354 ......FOIL, PROTECTIVE - UPPER SKID - RIGHT
    ......FOIL, PROTECTIVE - UPPER SKID - RIGHT
  • 45
    2621-338 ...DECAL, SKID PLATE - FORWARD - RIGHT
    ...DECAL, SKID PLATE - FORWARD - RIGHT
  • 46
    2621-336 ...DECAL, SKID PLATE - REAR - RIGHT
    ...DECAL, SKID PLATE - REAR - RIGHT
  • 47
    4718-585 PLATE, SKID W/DECALS - LEFT (INC. 48-52)
    PLATE, SKID W/DECALS - LEFT (INC. 48-52)
  • 48
    3718-785 ...PLATE, SKID W/O DECALS - LEFT (BLACK) (INC. 49-50)
    ...PLATE, SKID W/O DECALS - LEFT (BLACK) (INC. 49-50)
  • 49
    0617-641 ......FOAM, SKID PLATE - UPPER REAR - LEFT
    ......FOAM, SKID PLATE - UPPER REAR - LEFT
  • 50
    0617-639 ......FOAM, SKID PLATE - CENTER FRONT - LEFT
    ......FOAM, SKID PLATE - CENTER FRONT - LEFT
  • 51
    2621-339 ...DECAL, SKID PLATE - FORWARD - LEFT
    ...DECAL, SKID PLATE - FORWARD - LEFT
  • 52
    2621-337 ...DECAL, SKID PLATE - REAR - LEFT
    ...DECAL, SKID PLATE - REAR - LEFT
  • 53
    2623-005 CLIP, RETAINING
    CLIP, RETAINING
  • 54
    6606-592 PIN, RETAINING
    PIN, RETAINING
  • 55
    1623-129 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 56
    6606-342 FASCIA, FRONT - RIGHT - (BLACK)
    FASCIA, FRONT - RIGHT - (BLACK)
  • 56
    3718-303 FASCIA, FRONT - LEFT - (BLACK) (INC. 57)
    FASCIA, FRONT - LEFT - (BLACK) (INC. 57)
  • 57
    6606-405 ...FOIL, PROTECTIVE - FILLER PANEL - LEFT
    ...FOIL, PROTECTIVE - FILLER PANEL - LEFT
  • 58
    0123-903 TIE, CABLE - (11.5 IN.)
    TIE, CABLE - (11.5 IN.)
