DRIVE CLUTCH для Arctic Cat ZR 6000 R SX (GREEN) [S2015ACDPRUSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    0746-264 CLUTCH, DRIVE - UNCALIBRATED (INC. 2-3)
    CLUTCH, DRIVE - UNCALIBRATED (INC. 2-3)
  • 2
    0646-431 ...SCREW, SHOULDER
    ...SCREW, SHOULDER
  • 3
    0646-430 ...WASHER, LOCK
    ...WASHER, LOCK
  • 4
    0646-216 SPRING, DRIVE CLUTCH (BLACK/YELLOW)
    SPRING, DRIVE CLUTCH (BLACK/YELLOW)
  • 5
    4639-674 KIT,CAM ARM REPAIR 05- 09(WIDE) (INC. 6-9)
    KIT,CAM ARM REPAIR 05- 09(WIDE) (INC. 6-9)
  • 6
    8048-366 ...NUT, LOCK
    ...NUT, LOCK
  • 7
    1602-692 ...O-RING, 5/16 X 1/2 X 3/32 - VITON
    ...O-RING, 5/16 X 1/2 X 3/32 - VITON
  • 8
    1623-183 ......SCREW, SET
    ......SCREW, SET
  • 9
    0646-747 ...PIN, CAM ARM
    ...PIN, CAM ARM
  • 10
    0746-830 ARM, CAM (INC. 8)
    ARM, CAM (INC. 8)
