STEERING POST ASSY. для Arctic Cat T660 Turbo ST EFI EARLY BUILD - 2005 года выпуска

  • №
    Артикул
    Название
  • 1
    0705-992 POST, STEERING
    POST, STEERING
  • 2
    0605-513 RISER, HANDLEBAR, 4.44 IN.
    RISER, HANDLEBAR, 4.44 IN.
  • 2
    0605-491 RISER, HANDLEBAR, 5.44 IN.
    RISER, HANDLEBAR, 5.44 IN.
  • 2
    0605-512 RISER, HANDLEBAR, 6.44 IN.
    RISER, HANDLEBAR, 6.44 IN.
  • 2
    0605-514 RISER, HANDLEBAR, 2.44 IN.
    RISER, HANDLEBAR, 2.44 IN.
  • 3
    0705-355 CAP, ADJUSTING BLOCK (UPPER)
    CAP, ADJUSTING BLOCK (UPPER)
  • 4
    0705-881 CAP, ADJUSTING BLOCK (LOWER)
    CAP, ADJUSTING BLOCK (LOWER)
  • 5
    0623-872 SCREW, CAP-HSH-M8X1.25X30 GR 12
    SCREW, CAP-HSH-M8X1.25X30 GR 12
  • 6
    1606-079 CLOSURE,TUBE-7/8 X 16 GA-BLK
    CLOSURE,TUBE-7/8 X 16 GA-BLK
  • 7
    0623-814 SCREW, CAP-1/2HH 1/4 - 20 X 3.0
    SCREW, CAP-1/2HH 1/4 - 20 X 3.0
  • 8
    0605-406 CAP, BEARING HOUSING
    CAP, BEARING HOUSING
  • 9
    0405-020 BEARING, HALF
    BEARING, HALF
  • 10
    0605-147 HOUSING, BEARING
    HOUSING, BEARING
  • 11
    8048-366 NUT, HEX FLG-TOP LOCK 1/4-20 GR
    NUT, HEX FLG-TOP LOCK 1/4-20 GR
  • 12
    0623-025 NUT, LOCK3/8-24 NF
    NUT, LOCK3/8-24 NF
  • 13
    0623-044 WASHER, FLAT HARD .375 X.875
    WASHER, FLAT HARD .375 X.875
  • 14
    0705-427 PLATE, BACKING
    PLATE, BACKING
  • 15
    8020-130 SCREW, CAP-HFH 5/16-18 X0.75 G5
    SCREW, CAP-HFH 5/16-18 X0.75 G5
  • 16
    8048-426 NUT, LOCK
    NUT, LOCK
  • 17
    0605-423 BALL JOINT, STEERING (LEFT)
    BALL JOINT, STEERING (LEFT)
  • 18
    0123-917 NUT, HEX (LEFT)
    NUT, HEX (LEFT)
  • 19
    0605-626 TUBE, TIE ROD
    TUBE, TIE ROD
  • 20
    0623-294 NUT, HEX (RIGHT)
    NUT, HEX (RIGHT)
  • 21
    0605-504 BALL JOINT, TIE ROD (RIGHT)
    BALL JOINT, TIE ROD (RIGHT)
