SKI AND SPINDLE ASSEMBLY для Arctic Cat AC SNO PRO MOD - 2005 года выпуска

  • №
    Артикул
    Название
  • 1
    2603-590 SKI
    SKI
  • 2
    2603-589 HANDLE, PLASTIC (BLACK)
    HANDLE, PLASTIC (BLACK)
  • 3
    0623-928 NUT, HEX
    NUT, HEX
  • 4
    0623-927 WASHER, FLAT
    WASHER, FLAT
  • 5
    1623-455 SCREW, CAP
    SCREW, CAP
  • 6
    0623-925 SCREW, CAP
    SCREW, CAP
  • 7
    1703-808 SPINDLE, STEERING (RIGHT) (INC. 8, 11)
    SPINDLE, STEERING (RIGHT) (INC. 8, 11)
  • 7
    1703-809 SPINDLE, STEERING (LEFT) (INC. 8, 11)
    SPINDLE, STEERING (LEFT) (INC. 8, 11)
  • 8
    2603-481 BEARING
    BEARING
  • 9
    0603-083 BEARING
    BEARING
  • 10
    1623-010 FITTING, GREASE
    FITTING, GREASE
  • 11
    0603-647 INSERT, SPINDLE
    INSERT, SPINDLE
  • 12
    0603-034 AXLE, SPINDLE
    AXLE, SPINDLE
  • 13
    0702-747 SPRING, RETURN
    SPRING, RETURN
  • 14
    6611-630 DECAL, "AWS", SPINDLE (RIGHT)
    DECAL, "AWS", SPINDLE (RIGHT)
  • 14
    6611-631 DECAL, "AWS", SPINDLE (LEFT)
    DECAL, "AWS", SPINDLE (LEFT)
  • 15
    0623-831 CAP, SPINDLE
    CAP, SPINDLE
  • 16
    1603-960 DAMPER, SKI
    DAMPER, SKI
  • 17
    1703-875 PLATE, DAMPER
    PLATE, DAMPER
  • 18
    1623-433 KIT, HARDWARE (INC. 19, 22)
    KIT, HARDWARE (INC. 19, 22)
  • 19
    1623-434 SCREW, CAP
    SCREW, CAP
  • 20
    0623-929 WASHER, FLAT
    WASHER, FLAT
  • 21
    8040-545 NUT, HEX
    NUT, HEX
  • 22
    1603-513 INSERT, SKI SADDLE
    INSERT, SKI SADDLE
