SUSPENSION - FRONT FORK для Yamaha TMAX - 2010 года выпуска`
-
№АртикулНазвание
-
14B5-23102-00-00 FRONT FORK ASSY (LEFT)FRONT FORK ASSY (LEFT)
-
24B5-23126-00-00 TUBE, OUTER (LEFT)TUBE, OUTER (LEFT)
-
34B5-23110-00-00 INNER TUBE COMP.1INNER TUBE COMP.1
-
45EA-23171-30-00 PISTON, FRONT FORKPISTON, FRONT FORK
-
54B5-23170-00-00 CYLINDER COMP., FRONT FORKCYLINDER COMP., FRONT FORK
-
65EB-23125-00-00 METAL, SLIDE 1METAL, SLIDE 1
-
74V4-23146-L0-00 WASHER, OIL SEALWASHER, OIL SEAL
-
84PU-23145-01-00 OIL SEALOIL SEAL
-
94V4-23153-L0-00 RING, SNAPRING, SNAP
-
104PU-23144-00-00 SEAL, DUSTSEAL, DUST
-
114YR-23173-00-00 SPINDLE, TAPERSPINDLE, TAPER
-
12509-23158-L0-00 GASKETGASKET
-
13278-23181-50-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
144B5-23141-00-00 SPRING, FRONT FORKSPRING, FRONT FORK
-
153LR-23149-00-00 WASHER, SPRING UPPERWASHER, SPRING UPPER
-
165WM-23118-00-00 SPACERSPACER
-
173TJ-23111-00-00 BOLT, CAPBOLT, CAP
-
184V4-23188-L0-00 O-RINGO-RING
-
194B5-23103-00-00 FRONT FORK ASSY (RIGHT)FRONT FORK ASSY (RIGHT)
-
204B5-23136-00-00 TUBE, OUTER (RIGHT)TUBE, OUTER (RIGHT)
-
214B5-23110-00-00 INNER TUBE COMP.1INNER TUBE COMP.1
-
225EA-23171-30-00 PISTON, FRONT FORKPISTON, FRONT FORK
-
234B5-23170-00-00 CYLINDER COMP., FRONT FORKCYLINDER COMP., FRONT FORK
-
245EB-23125-00-00 METAL, SLIDE 1METAL, SLIDE 1
-
254V4-23146-L0-00 WASHER, OIL SEALWASHER, OIL SEAL
-
264PU-23145-01-00 OIL SEALOIL SEAL
-
274V4-23153-L0-00 RING, SNAPRING, SNAP
-
284PU-23144-00-00 SEAL, DUSTSEAL, DUST
-
294YR-23173-00-00 SPINDLE, TAPERSPINDLE, TAPER
-
30509-23158-L0-00 GASKETGASKET
-
31278-23181-50-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
324B5-23141-00-00 SPRING, FRONT FORKSPRING, FRONT FORK
-
333LR-23149-00-00 WASHER, SPRING UPPERWASHER, SPRING UPPER
-
345WM-23118-00-00 SPACERSPACER
-
353TJ-23111-00-00 BOLT, CAPBOLT, CAP
-
364V4-23188-L0-00 O-RINGO-RING
-
3791314-08040-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
384PU-2331G-00-00 COVERCOVER
-
394B5-23340-10-00 UNDER BRACKET COMP.UNDER BRACKET COMP.
-
4091314-08025-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
4193399-99957-00 BEARINGBEARING
-
423FV-23462-00-00 SEAL, STEERINGSEAL, STEERING
