WHEEL - REAR для Yamaha MORPHOUS - 2008 года выпуска`
-
№АртикулНазвание
-
11B7-25338-00-00 CAST WHEEL, REARCAST WHEEL, REAR
-
294113-13008-00 TIRE (130/70-13 M/C 63P D305) (DUNLOP)TIRE (130/70-13 M/C 63P D305) (DUNLOP)
-
393900-00025-00 VALVE, RIMVALVE, RIM
-
45MT-25398-00-00 BALANCER, WHEEL (10G)BALANCER, WHEEL (10G)
-
45MT-25398-10-00 BALANCER, WHEEL (20G)BALANCER, WHEEL (20G)
-
45MT-25398-20-00 BALANCER, WHEEL (30G)BALANCER, WHEEL (30G)
-
590185-14150-00 NUT, SELF-LOCKINGNUT, SELF-LOCKING
