SUSPENSION - FRONT A - ARM W/ TIE RODS для Polaris XPLORER 400 (A00CG38CA) - 2000 года выпуска`
-
№АртикулНазвание
-
17542403 NUT, LOCKNUT, LOCK
-
25333367 BUSHINGBUSHING
-
31820567 TIE ROD KIT (INCL. 4-9) (BUILT BEFORE 8/16/99)TIE ROD KIT (INCL. 4-9) (BUILT BEFORE 8/16/99)
-
31820805 TIE, ROD ASSY. (1/2-20X13.4) (INCL. 4-9) (BUILT AFTER 8/16/99)TIE, ROD ASSY. (1/2-20X13.4) (INCL. 4-9) (BUILT AFTER 8/16/99)
-
45411291 SEAL, BOOT, ROD END, 1/2 INSEAL, BOOT, ROD END, 1/2 IN
-
57061034 ROD END (RIGHT)ROD END (RIGHT)
-
67542711 NUT, JAMNUT, JAM
-
75020926 ROD, TIEROD, TIE
-
87547028 NUT, JAM (LEFT)NUT, JAM (LEFT)
-
97061033 ROD END KIT (BUILT BEFORE 8/16/99)ROD END KIT (BUILT BEFORE 8/16/99)
-
97061054 ROD, END, 10MM, 42 DEG (LEFT) (BUILT AFTER 8/16/99)ROD, END, 10MM, 42 DEG (LEFT) (BUILT AFTER 8/16/99)
-
105411920 BOOT, SEAL, ROD END, 10MMBOOT, SEAL, ROD END, 10MM
-
117517674 BOLT, WASHER HEAD (BUILT AFTER 8/16/99)BOLT, WASHER HEAD (BUILT AFTER 8/16/99)
-
127555806 WASHER (BUILT BEFORE 8/16/99)WASHER (BUILT BEFORE 8/16/99)
-
127556099 WASHER (BUILT AFTER 8/16/99)WASHER (BUILT AFTER 8/16/99)
-
137546904 NUT, CASTLENUT, CASTLE
-
147661203 PIN, COTTERPIN, COTTER
-
157080927 BALL-JOINT, 52 DEGBALL-JOINT, 52 DEG
-
165211121 BRACKET, BALL JOINTBRACKET, BALL JOINT
-
177512284 BOLT, SOCKETBOLT, SOCKET
-
185410548 BOOT, RUBBERBOOT, RUBBER
-
197542438 NUT, CASTLENUT, CASTLE
-
205431150 SHIELD, CV JOINT (LEFT/BLACK)SHIELD, CV JOINT (LEFT/BLACK)
-
205431149 SHIELD, CV JOINT (RIGHT/BLACK)SHIELD, CV JOINT (RIGHT/BLACK)
-
217512084 SCREWSCREW
-
225433066 BUSHING, A ARM LONG (BLACK)BUSHING, A ARM LONG (BLACK)
-
235020677 BUSHING, A-ARM SPACERBUSHING, A-ARM SPACER
-
245020681 SHAFT, A-ARMSHAFT, A-ARM
-
252201157 A FRAME, KIT (LEFT/BLACK)A FRAME, KIT (LEFT/BLACK)
-
252201158 A FRAME, KIT (RIGHT/BLACK)A FRAME, KIT (RIGHT/BLACK)
-
267080433 ZERK, FITTING, THREADEDZERK, FITTING, THREADED
-
287512492 SCREWSCREW
-
297552603 WASHERWASHER
-
307517527 BOLTBOLT
-
317515415 BOLTBOLT
