ENGINE CASE для Ktm 660 SMC - 2004 года выпуска

  • №
    Артикул
    Название
  • 1
    5733000004423 ENGINE CASE CPL.W.TRAN.BEAR.
    ENGINE CASE CPL.W.TRAN.BEAR.
  • 5
    50130027000 DOWEL 19 X15,1X12
    DOWEL 19 X15,1X12
  • 6
    51030026100 DOWEL 17 X14 X12
    DOWEL 17 X14 X12
  • 7
    50130010000 CRANK CASE BUSH
    CRANK CASE BUSH
  • 9
    58033097000 NEEDLE BEARING HK 2216
    NEEDLE BEARING HK 2216
  • 10
    58330011000 SHIFT MECHANISM SUPPORT
    SHIFT MECHANISM SUPPORT
  • 11
    49030090000 DOWEL 9,8 X 7 X 10
    DOWEL 9,8 X 7 X 10
  • 15
    56530017000 RETAINING BRACKET
    RETAINING BRACKET
  • 16
    0991060166 FL.HEAD SCR.DIN7991-M6X16 10.9
    FL.HEAD SCR.DIN7991-M6X16 10.9
  • 18
    0015080163 HH COLLAR SCREW M 8X16 WS=10
    HH COLLAR SCREW M 8X16 WS=10
  • 19
    0603082121 SEAL RING CU DIN7603- 8X12X1
    SEAL RING CU DIN7603- 8X12X1
  • 20
    58530039300 ENGI.CASE GASKET POLY. 0,43 04
    ENGI.CASE GASKET POLY. 0,43 04
  • 21
    0985050103 OVAL HEAD SCR. DIN7985-M 5X10
    OVAL HEAD SCR. DIN7985-M 5X10
  • 23
    0412174012 CYLIND.ROLL.NJ 203 ECP/C3
    CYLIND.ROLL.NJ 203 ECP/C3
  • 24
    0625618050 BALL BEARING 61805 C3
    BALL BEARING 61805 C3
  • 26
    60030064070 OIL JET 70 M6X0,75 WS8
    OIL JET 70 M6X0,75 WS8
  • 27
    49030029000 OIL DRAIN PLUG M10X10 AH-WS=6
    OIL DRAIN PLUG M10X10 AH-WS=6
  • 28
    49130450050 TUBE LW 3
    TUBE LW 3
  • 29
    0603100141 COPPER GASKET DIN7603-10X14X1
    COPPER GASKET DIN7603-10X14X1
  • 30
    5833010124423 CLUTCH COVER CPL. GREY
    CLUTCH COVER CPL. GREY
  • 31
    58530025000 CLUTCH COVER GASKET
    CLUTCH COVER GASKET
  • 33
    58030020000 PLUG M 24X3
    PLUG M 24X3
  • 34
    0770191015 O-RING 19,00X3,00 NBR
    O-RING 19,00X3,00 NBR
  • 35
    61030019050 CIRCLIP OIL LEVEL GLASS
    CIRCLIP OIL LEVEL GLASS
  • 36
    59030019000 OIL LEVEL GLASS G 1777 Y
    OIL LEVEL GLASS G 1777 Y
  • 38
    58333041000 BUMP RUBBER
    BUMP RUBBER
  • 39
    58030047615 CHAIN DAMPER SHEET
    CHAIN DAMPER SHEET
  • 42
    58030050700 CHAIN COVER BLACK
    CHAIN COVER BLACK
  • 43
    0912060303 AH SCREW DIN0912-M 6X30
    AH SCREW DIN0912-M 6X30
  • 44
    58030021000 OILDRAIN PLUG W.MAG. M 12X1,5
    OILDRAIN PLUG W.MAG. M 12X1,5
  • 45
    58038017100 CU-SEAL RING DIN7603-22X27X2
    CU-SEAL RING DIN7603-22X27X2
  • 46
    58038019100 OIL DRAIN PLUG M22X1,5
    OIL DRAIN PLUG M22X1,5
  • 47
    58038022000 CU-SEAL RING DIN7603-12X18X1,5
    CU-SEAL RING DIN7603-12X18X1,5
  • 48
    0908120153 PLUG DIN0908-M12X1,5
    PLUG DIN0908-M12X1,5
  • 50
    58538023000 OIL PRES.SPRING 5 BAR RED
    OIL PRES.SPRING 5 BAR RED
  • 51
    58038028000 VALVE PISTON D=10MM
    VALVE PISTON D=10MM
  • 55
    58430099200 GASKET SET
    GASKET SET
  • 60
    0015060253 HH COLLAR SCREW M 6X25 WS=8
    HH COLLAR SCREW M 6X25 WS=8
  • 61
    0015060303 HH COLLAR SCREW M 6X30 WS=8
    HH COLLAR SCREW M 6X30 WS=8
  • 62
    0015060353 HH COLLAR SCREW M 6X35 WS=8
    HH COLLAR SCREW M 6X35 WS=8
  • 63
    0015060403 HH COLLAR SCREW M 6X40 W5=8
    HH COLLAR SCREW M 6X40 W5=8
  • 66
    0015060553 HH COLLAR SCREW M 6X55 WS=8
    HH COLLAR SCREW M 6X55 WS=8
  • 68
    0015060653 HH COLLAR SCREW M 6X65 WS=8
    HH COLLAR SCREW M 6X65 WS=8
