BELT GUARD ASSEMBLY для Arctic Cat XF 7000 LXR 137 (GREEN) [S2015XFULXUSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    2707-277 GUARD, BELT (INC. 2-4)
    GUARD, BELT (INC. 2-4)
  • 2
    0617-733 ...PAD, GAS TANK
    ...PAD, GAS TANK
  • 3
    9611-691 ...DECAL, WARNING (FRENCH)
    ...DECAL, WARNING (FRENCH)
  • 4
    9611-690 ...DECAL, WARNING (ENGLISH)
    ...DECAL, WARNING (ENGLISH)
  • 5
    0623-797 SCREW,SELF TAP-TSTH 10-12X1/2 WO/GP
    SCREW,SELF TAP-TSTH 10-12X1/2 WO/GP
  • 6
    1623-052 CLIP, U-NUT
    CLIP, U-NUT
  • 7
    8060-686 RIVET,BLIND-DH SS64 ZINC
    RIVET,BLIND-DH SS64 ZINC
  • 8
    0623-966 SCREW,SELF TAP-HWH M6 X 12 Z (TRI LOB)
    SCREW,SELF TAP-HWH M6 X 12 Z (TRI LOB)
