OIL TANK ASSEMBLY для Arctic Cat M 9000 SNO PRO LTD 162 (ORANGE) (EARLY BUILD) [S2015M9NLEUSO] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    0770-963 TANK, OIL
    TANK, OIL
  • 2
    2670-257 GLASS, SIGHT
    GLASS, SIGHT
  • 3
    1602-213 O-RING
    O-RING
  • 4
    2602-099 PLUG, DRAIN
    PLUG, DRAIN
  • 5
    2670-219 TUBE, OIL TANK
    TUBE, OIL TANK
  • 6
    1623-814 SCREW,MAG FORM-TXPH-M6X2.0X24
    SCREW,MAG FORM-TXPH-M6X2.0X24
  • 7
    2670-224 CAP, OIL TANK (INC. 8)
    CAP, OIL TANK (INC. 8)
  • 8
    2670-135 ...SEAL, CAP - OIL TANK
    ...SEAL, CAP - OIL TANK
  • 9
    1623-969 SCREW,MAG FORM-TXPH-M6X2.0X12 Z & C
    SCREW,MAG FORM-TXPH-M6X2.0X12 Z & C
  • 10
    2670-218 FITTING, ELBOW NIPPLE,OIL TANK-VENT
    FITTING, ELBOW NIPPLE,OIL TANK-VENT
  • 11
    0670-183 O-RING, 5/8 X 13/16 OD
    O-RING, 5/8 X 13/16 OD
  • 12
    2670-406 O-RING,OIL TANK-0.984 ID X 0.139 THK
    O-RING,OIL TANK-0.984 ID X 0.139 THK
  • 13
    2670-221 FITTING, OIL RETURN - ENGINE
    FITTING, OIL RETURN - ENGINE
  • 14
    2623-088 CLAMP,HOSE-23/35
    CLAMP,HOSE-23/35
  • 15
    0610-840 HOSE,25.4MM DIA X 75MM-SAE J30
    HOSE,25.4MM DIA X 75MM-SAE J30
  • 16
    2670-226 TUBE, OIL RETURN
    TUBE, OIL RETURN
  • 17
    2670-170 FITTING, OIL RETURN - ENGINE
    FITTING, OIL RETURN - ENGINE
  • 18
    0648-441 O-RING,ADJUSTER SHEAVE (2-121)
    O-RING,ADJUSTER SHEAVE (2-121)
  • 19
    8471-616 SCREW,MACH-TSPNH M6X1.0X16 CL8.8 Z & (BLACK)
    SCREW,MACH-TSPNH M6X1.0X16 CL8.8 Z & (BLACK)
  • 20
    2670-169 FITTING, OIL SUPPLY - ENGINE
    FITTING, OIL SUPPLY - ENGINE
  • 21
    0610-839 HOSE, OIL FEED
    HOSE, OIL FEED
  • 22
    0673-459 O-RING,3/4ID X 1/16 (-018)
    O-RING,3/4ID X 1/16 (-018)
  • 23
    2670-222 SCREEN, OIL TANK
    SCREEN, OIL TANK
  • 24
    2670-290 O-RING,OIL TANK(2-120)
    O-RING,OIL TANK(2-120)
  • 25
    2670-220 FITTING, OIL SUPPLY - ENGINE
    FITTING, OIL SUPPLY - ENGINE
  • 26
    2670-227 TUBE, OIL FEED
    TUBE, OIL FEED
  • 27
    0610-869 HOSE, BREATHER - UPPER
    HOSE, BREATHER - UPPER
  • 28
    1623-288 CLAMP,HOSE-SPRING (12W X 25)
    CLAMP,HOSE-SPRING (12W X 25)
  • 29
    1623-182 CLAMP, INERCOOLER-SMALL
    CLAMP, INERCOOLER-SMALL
  • 30
    2670-267 TUBE,BREATHER,OIL TANK-W/CHECK VALVE
    TUBE,BREATHER,OIL TANK-W/CHECK VALVE
  • 31
    1623-958 GROMMET, RUBBER - .5"ID X 1.00" OD X .09 GR
    GROMMET, RUBBER - .5"ID X 1.00" OD X .09 GR
  • 32
    0610-844 HOSE, BREATHER - OIL TANK
    HOSE, BREATHER - OIL TANK
  • 33
    1623-292 CLAMP,HOSE-SPRING (12W X 29)
    CLAMP,HOSE-SPRING (12W X 29)
  • 34
    0610-880 HOSE, BREATHER - OIL SEPARATOR/AIR FILTER
    HOSE, BREATHER - OIL SEPARATOR/AIR FILTER
  • 35
    2670-324 FITTING,ELBOW-PLASTIC
    FITTING,ELBOW-PLASTIC
  • 36
    1619-486 CONDUIT, FLEXIBLE - 5 FT
    CONDUIT, FLEXIBLE - 5 FT
  • 37
    0610-843 HOSE, BREATHER - OIL SEPARATOR
    HOSE, BREATHER - OIL SEPARATOR
  • 38
    1048-063 LOCTITE,5699-GASKET MAKER (70ML)
    LOCTITE,5699-GASKET MAKER (70ML)
