COOLING ASSEMBLY для Arctic Cat M 9000 SNO PRO LTD 162 (ORANGE) (EARLY BUILD) [S2015M9NLEUSO] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    0713-079 EXCHANGER, HEAT
    EXCHANGER, HEAT
  • 2
    8060-702 RIVET,BLIND-DH SS62 (BLACK)
    RIVET,BLIND-DH SS62 (BLACK)
  • 3
    8422-502 NUT, M5 X 1 NYL Z & Y
    NUT, M5 X 1 NYL Z & Y
  • 4
    8476-516 SCREW,MACH-TSTRH M5X0.8X16 Z & Y
    SCREW,MACH-TSTRH M5X0.8X16 Z & Y
  • 5
    8060-706 RIVET,BLIND-DH SS64 (BLACK)
    RIVET,BLIND-DH SS64 (BLACK)
  • 6
    0619-206 FOIL, PROTECTIVE
    FOIL, PROTECTIVE
  • 7
    2623-088 CLAMP,HOSE-23/35
    CLAMP,HOSE-23/35
  • 8
    0610-866 HOSE, COOLANT - COOLANT TUBE/HEAT EXCHANGER
    HOSE, COOLANT - COOLANT TUBE/HEAT EXCHANGER
  • 9
    0613-050 TUBE, COOLANT - ENGINE/HEAT EXCHANGER
    TUBE, COOLANT - ENGINE/HEAT EXCHANGER
  • 10
    8409-017 SCREW,CAP-HFH M10X1.25X16 CL10.9W/2353
    SCREW,CAP-HFH M10X1.25X16 CL10.9W/2353
  • 11
    1623-916 CLAMP,CABLE-1" INSUL-.406 MTG
    CLAMP,CABLE-1" INSUL-.406 MTG
  • 12
    0608-668 BRACKET, MOUNTING - COOLANT TUBE
    BRACKET, MOUNTING - COOLANT TUBE
  • 13
    1623-637 CLIP, U-NUT
    CLIP, U-NUT
  • 14
    0423-044 CLAMP,TUBE-1" ARDEN(COV 1709 ZI)
    CLAMP,TUBE-1" ARDEN(COV 1709 ZI)
  • 15
    0610-865 HOSE, COOLANT - THERMOSTAT/COOLANT TUBE
    HOSE, COOLANT - THERMOSTAT/COOLANT TUBE
  • 16
    1623-973 CLAMP,HOSE - NOM OD 19.1 - #CTL-12
    CLAMP,HOSE - NOM OD 19.1 - #CTL-12
  • 17
    0610-845 HOSE,COOLANT-TURBO
    HOSE,COOLANT-TURBO
  • 18
    1619-356 CONDUIT, HIGH TEMP
    CONDUIT, HIGH TEMP
  • 19
    1623-281 CLAMP,HOSE-SPRING (12W X 18)
    CLAMP,HOSE-SPRING (12W X 18)
  • 20
    0610-849 HOSE, COOLANT - ENGINE/COOLANT-OIL SEPARATOR TANK
    HOSE, COOLANT - ENGINE/COOLANT-OIL SEPARATOR TANK
  • 21
    8408-026 SCREW,CAP-HFH M10X1.25X25 CL8.8 W/2353
    SCREW,CAP-HFH M10X1.25X25 CL8.8 W/2353
  • 22
    0613-048 BRACKET, MOUNTING - COOLANT-OIL SEPARATOR TANK
    BRACKET, MOUNTING - COOLANT-OIL SEPARATOR TANK
  • 23
    0613-070 TANK, COOLANT-OIL SEPARATOR - ASSEMBLY
    TANK, COOLANT-OIL SEPARATOR - ASSEMBLY
  • 24
    0613-120 HOSE,OVERFLOW-COOLANT
    HOSE,OVERFLOW-COOLANT
  • 25
    0610-842 HOSE, COOLANT - HEAT EXCHANGER/COOLANT-OIL SEPARATOR TANK
    HOSE, COOLANT - HEAT EXCHANGER/COOLANT-OIL SEPARATOR TANK
  • 26
    0623-540 TIE, CABLE - TRIPLE
    TIE, CABLE - TRIPLE
  • 27
    2606-284 CAP, MINI RADIATOR
    CAP, MINI RADIATOR
  • 28
    1623-278 CLAMP,HOSE-SPRING (12W X 15)
    CLAMP,HOSE-SPRING (12W X 15)
  • 29
    0610-841 HOSE, COOLANT - COOLANT-OIL SEPARATOR TANK/THROTTLE BODY
    HOSE, COOLANT - COOLANT-OIL SEPARATOR TANK/THROTTLE BODY
  • 30
    0619-776 CONDUIT - 5 FT
    CONDUIT - 5 FT
  • 31
    0610-840 HOSE,25.4MM DIA X 75MM-SAE J30
    HOSE,25.4MM DIA X 75MM-SAE J30
  • 32
    0613-049 TUBE, COOLANT - CYLINDER HEAD/PUMP
    TUBE, COOLANT - CYLINDER HEAD/PUMP
  • 33
    0610-867 HOSE, COOLANT
    HOSE, COOLANT
  • 34
    1623-285 CLAMP,HOSE-SPRING (12W X 22)
    CLAMP,HOSE-SPRING (12W X 22)
  • 35
    0613-051 TUBE , COOLANT - THERMOSTAT/ WATER PUMP
    TUBE , COOLANT - THERMOSTAT/ WATER PUMP
  • 36
    0613-138 BRACKET, RETAINING
    BRACKET, RETAINING
  • 37
    3007-825 BOLT,WATER PIPE
    BOLT,WATER PIPE
  • 38
    2623-006 CLAMP,CABLE-.625 INSUL-.03 MTG
    CLAMP,CABLE-.625 INSUL-.03 MTG
