DRIVE TRAIN SHAFTS AND BRAKE ASSEMBLIES для Arctic Cat AC 600 MODIFIED SNO PRO (GREEN) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    0728-168 TRACK DRIVE ASSEMBLY (INC. 2-4)
    TRACK DRIVE ASSEMBLY (INC. 2-4)
  • 2
    1602-592 ...SPROCKET, DRIVE
    ...SPROCKET, DRIVE
  • 3
    0702-412 ...PLATE, FLANGE
    ...PLATE, FLANGE
  • 4
    1602-601 ...BEARING, 1 1/16 IN. W/O LOCK COLLAR
    ...BEARING, 1 1/16 IN. W/O LOCK COLLAR
  • 5
    0630-180 REGULATOR, VOLTAGE
    REGULATOR, VOLTAGE
  • 6
    8047-426 NUT, LOCK
    NUT, LOCK
  • 7
    1602-795 DISC, BRAKE
    DISC, BRAKE
  • 8
    0702-771 SHAFT, DRIVEN (INC. 9-11)
    SHAFT, DRIVEN (INC. 9-11)
  • 9
    1602-114 ...COLLAR, HUB - BRAKE DISC
    ...COLLAR, HUB - BRAKE DISC
  • 10
    1602-233 ...BEARING, 1 IN. W/O LOCK COLLAR
    ...BEARING, 1 IN. W/O LOCK COLLAR
  • 11
    1602-367 ...SPACER
    ...SPACER
  • 12
    0101-076 KEY
    KEY
  • 13
    3606-581 BRACKET, SPEED SENSOR
    BRACKET, SPEED SENSOR
  • 14
    8005-402 SCREW, CAP
    SCREW, CAP
  • 15
    0630-167 MAGNET, DISC
    MAGNET, DISC
  • 16
    0623-118 WASHER,FLAT-1.00 X1.43 X.030**
    WASHER,FLAT-1.00 X1.43 X.030**
  • 16
    0623-119 WASHER,FLAT-1.00 X1.43 X.075**
    WASHER,FLAT-1.00 X1.43 X.075**
  • 17
    0616-032 O-RING
    O-RING
  • 18
    0648-770 SHAFT, STUB
    SHAFT, STUB
  • 19
    0123-053 WASHER**
    WASHER**
  • 20
    0726-272 CLUTCH, DRIVEN
    CLUTCH, DRIVEN
  • 21
    0123-019 WASHER
    WASHER
  • 22
    8002-139 SCREW, CAP
    SCREW, CAP
  • 23
    1602-639 CALIPER, BRAKE - ASSEMBLY (INC. 24-34)
    CALIPER, BRAKE - ASSEMBLY (INC. 24-34)
  • 24
    8005-679 ...SCREW, CAP
    ...SCREW, CAP
  • 25
    8050-272 ...WASHER
    ...WASHER
  • 26
    0602-590 ...FITTING, ADAPTER
    ...FITTING, ADAPTER
  • 28
    0602-729 ...O-RING, HOUSING
    ...O-RING, HOUSING
  • 29
    0602-583 ...O-RING
    ...O-RING
  • 30
    0602-708 ...PISTON
    ...PISTON
  • 31
    0602-707 ...SCREW, BLEED - ASSEMBLY
    ...SCREW, BLEED - ASSEMBLY
  • 33
    0702-229 ...PAD, BRAKE - SET (INC. 34)
    ...PAD, BRAKE - SET (INC. 34)
  • 34
    0602-706 ......PIN, RETAINING
    ......PIN, RETAINING
  • 35
    8020-315 SCREW, CAP
    SCREW, CAP
