CYLINDER AND HEAD ASSEMBLY для Arctic Cat AC 600 MODIFIED SNO PRO (GREEN) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    2900-034 HEAD, CYLINDER (INC. 2)
    HEAD, CYLINDER (INC. 2)
  • 2
    3006-321 ...PIN, DOWEL
    ...PIN, DOWEL
  • *
    2900-033 ...INSERT, BILLET - CYLINDER HEAD (NOT ILLUSTRATED)
    ...INSERT, BILLET - CYLINDER HEAD (NOT ILLUSTRATED)
  • 3
    2900-019 BOLT, FLANGED HEAD W/10 MM HEX
    BOLT, FLANGED HEAD W/10 MM HEX
  • 4
    3004-459 BOLT
    BOLT
  • 5
    3003-227 O-RING
    O-RING
  • 6
    0217-709 PLUG, SPARK (BR9EYA)
    PLUG, SPARK (BR9EYA)
  • 7
    3003-335 O-RING, CYLINDER HEAD - INNER
    O-RING, CYLINDER HEAD - INNER
  • 8
    2900-004 O-RING, CYLINDER HEAD - OUTER
    O-RING, CYLINDER HEAD - OUTER
  • 9
    3005-747 HOLDER, EXHAUST VALVE CABLE
    HOLDER, EXHAUST VALVE CABLE
  • 10
    2900-021 BOLT
    BOLT
  • 11
    3003-503 GASKET, EXHAUST
    GASKET, EXHAUST
  • 12
    2900-030 CYLINDER
    CYLINDER
  • 13
    2900-009 GASKET, CYLINDER
    GASKET, CYLINDER
  • 14
    3004-975 PIN, DOWEL
    PIN, DOWEL
  • 15
    2900-020 BOLT
    BOLT
  • 16
    2900-011 VALVE, EXHAUST
    VALVE, EXHAUST
  • 17
    3006-321 PIN, DOWEL
    PIN, DOWEL
  • 18
    2900-023 GASKET, EXHAUST VALVE
    GASKET, EXHAUST VALVE
  • 19
    2900-012 PLATE, EXHAUST VALVE
    PLATE, EXHAUST VALVE
  • 20
    3005-860 STOPPER, EXHAUST VALVE
    STOPPER, EXHAUST VALVE
  • 21
    3006-484 SPRING
    SPRING
  • 22
    3005-983 PIN, EXHAUST VALVE
    PIN, EXHAUST VALVE
  • 23
    2900-023 GASKET, EXHAUST VALVE COVER
    GASKET, EXHAUST VALVE COVER
  • 24
    3006-425 COVER, EXHAUST VALVE
    COVER, EXHAUST VALVE
  • 25
    2900-027 BOLT
    BOLT
  • 26
    3005-226 O-RING
    O-RING
  • 27
    3005-744 BOLT
    BOLT
  • 28
    3005-808 CLAMP
    CLAMP
  • 29
    3006-736 CABLE, EXHAUST VALVE
    CABLE, EXHAUST VALVE
  • 30
    3006-322 SEAL, OIL - EXHAUST VALVE
    SEAL, OIL - EXHAUST VALVE
  • 31
    2900-024 BOLT
    BOLT
  • 32
    2900-025 O-RING, CYLINDER HEAD - SPARK PLUG
    O-RING, CYLINDER HEAD - SPARK PLUG
