HANDLEBAR - LEVERS / SWITCHES для Suzuki VZ1500 L5 BOULEVARD M90 - 2015 года выпуска
-
№АртикулНазвание
-
137200-48GA1 SWITCH ASSY, HANDLE, RIGHT HANDSWITCH ASSY, HANDLE, RIGHT HAND
-
202112-0545B ...SCREW...SCREW
-
302112-0510B ...SCREW...SCREW
-
402112-0535B ...SCREW...SCREW
-
509407-14407 CLAMP (L:145)CLAMP (L:145)
-
637400-48G60 SWITCH ASSY, HANDLE, LEFT HANDSWITCH ASSY, HANDLE, LEFT HAND
-
702112-0530B ...SCREW...SCREW
-
802112-0545B ...SCREW...SCREW
-
909407-14407 CLAMP (L:145)CLAMP (L:145)
