MID ANGLE DRIVE для Polaris RANGER 500 [A99RF50AA] - 1999 года выпуска

  • №
    Артикул
    Название
  • -
    1341239 MID ANGLE DRIVE (INCL. 1-16)
    MID ANGLE DRIVE (INCL. 1-16)
  • 1
    7512407 BOLT
    BOLT
  • 2
    7556042 WASHER, FLAT
    WASHER, FLAT
  • 3
    5131713 COVER
    COVER
  • 4
    5411374 O-RING
    O-RING
  • 5
    3554513 CUP, BEARING
    CUP, BEARING
  • 6
    1341238 SHAFT ASM, GEAR
    SHAFT ASM, GEAR
  • 7
    5010455 SHIM, RING GEAR, .025
    SHIM, RING GEAR, .025
  • 7
    5010447 SHIM, RING GEAR, .030
    SHIM, RING GEAR, .030
  • 7
    5010456 SHIM, RING GEAR, .032
    SHIM, RING GEAR, .032
  • 7
    5010457 SHIM, RING GEAR, .035
    SHIM, RING GEAR, .035
  • 7
    5010458 SHIM, RING GEAR, .040
    SHIM, RING GEAR, .040
  • 8
    1341258 HSG.ASM, MID., GEAR (INCL. 10, 16)
    HSG.ASM, MID., GEAR (INCL. 10, 16)
  • 9
    3233256 SEAL-TRIPLE LIP
    SEAL-TRIPLE LIP
  • 10
    7052195 PLUG, DRAIN, 0-RING
    PLUG, DRAIN, 0-RING
  • 11
    5010459 SHIM, PINION, ANGLEDRIVE, .025
    SHIM, PINION, ANGLEDRIVE, .025
  • 11
    5010449 SHIM, PINION, ANGLEDRIVE, .030
    SHIM, PINION, ANGLEDRIVE, .030
  • 11
    5010448 SHIM, .050, PINION
    SHIM, .050, PINION
  • 11
    5010460 SHIM, PINION, ANGLEDRIVE, .035
    SHIM, PINION, ANGLEDRIVE, .035
  • 11
    5010461 SHIM, PINION, ANGLEDRIVE, .040
    SHIM, PINION, ANGLEDRIVE, .040
  • 12
    1341260 PINION ASM.
    PINION ASM.
  • 13
    3610066 SEAL, PINION HSG.
    SEAL, PINION HSG.
  • 14
    5131761 COVER, PINION, MACH.
    COVER, PINION, MACH.
  • 15
    5411375 O-RING
    O-RING
  • 16
    3233321 SCREW
    SCREW
