RAIL ASSEMBLY W/ IDLER WHEELS для Polaris 800 RMK 159 BUILT BEFORE 1/1/02 (S03NM8CS) - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    7512007 BOLT
    BOLT
  • 2
    7555792 WASHER
    WASHER
  • 3
    7510504 SCREW
    SCREW
  • 4
    7555783 WASHER, FLAT
    WASHER, FLAT
  • 5
    5521498 BUMPER, JOUNCE REAR
    BUMPER, JOUNCE REAR
  • 5
    5432946 LINER, BUMPER
    LINER, BUMPER
  • 6
    1541806 ASSY. - RAIL, 159 (LEFT) (INCL. 1, 2, 3, 4, 5, 6, 18, 19, 30, 31)
    ASSY. - RAIL, 159 (LEFT) (INCL. 1, 2, 3, 4, 5, 6, 18, 19, 30, 31)
  • 6
    1541807 ASSY. - RAIL, 159 (RIGHT) (INCL. 1, 2, 3, 4, 5, 6, 18, 19, 30, 31)
    ASSY. - RAIL, 159 (RIGHT) (INCL. 1, 2, 3, 4, 5, 6, 18, 19, 30, 31)
  • 7
    7542324 NUT, NYLOK
    NUT, NYLOK
  • 8
    5245411 BRACKET - RAIL, REINF
    BRACKET - RAIL, REINF
  • 9
    7542439 NUT, NYLOK
    NUT, NYLOK
  • 10
    7515317 BOLT
    BOLT
  • 11
    7515346 SCREW
    SCREW
  • 12
    7556179 WASHER - SPRING,
    WASHER - SPRING,
  • 13
    1590317 ASSY. - WHEEL, BOGIE, PLAIN, 5.62
    ASSY. - WHEEL, BOGIE, PLAIN, 5.62
  • 14
    5631065 BLOCK - WHEEL MOUNT, LWT
    BLOCK - WHEEL MOUNT, LWT
  • 15
    7541925 NUT, NYLOK
    NUT, NYLOK
  • 16
    7517227 SCREW
    SCREW
  • 17
    7542404 NUT
    NUT
  • 18
    5130530 BLOCK - IDLER BOLT ADJ.
    BLOCK - IDLER BOLT ADJ.
  • 19
    7621501 RIVET
    RIVET
  • 20
    1590318-312 ASSY. - WHEEL SCROLLED, 5.62, I BLUE (INCL. 21, 22)
    ASSY. - WHEEL SCROLLED, 5.62, I BLUE (INCL. 21, 22)
  • 21
    3514303 BEARING (1 PER WHEEL)
    BEARING (1 PER WHEEL)
  • 22
    7718407 RING - RETAINING (1 PER WHEEL)
    RING - RETAINING (1 PER WHEEL)
  • 23
    7515438 BOLT
    BOLT
  • 24
    7555983 WASHER, FLAT
    WASHER, FLAT
  • 25
    5434334 GUIDE - SPRING SQUARE
    GUIDE - SPRING SQUARE
  • 25
    7661123 PIN - CLEVIS 3/16X1 1/4
    PIN - CLEVIS 3/16X1 1/4
  • 25
    7661644 PIN, HITCH
    PIN, HITCH
  • 26
    5333948 SPACER
    SPACER
  • 27
    7661845 RIVET
    RIVET
  • 28
    5521595-309 SLIDER, .45/74", SERVICE, BASIC
    SLIDER, .45/74", SERVICE, BASIC
  • 29
    7515199 SCREW
    SCREW
  • 30
    7541925 NUT, NYLOK
    NUT, NYLOK
  • 31
    5434355 CAP - RAIL TIP UHMW
    CAP - RAIL TIP UHMW
