SEAT W/ GAS TANK ASSEMBLY для Polaris 500 XC EDGE (S03NP5AS) - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    1240066 FUEL CAP,12 GAL W/GAUGE,13.50
    FUEL CAP,12 GAL W/GAUGE,13.50
  • 2
    2683073 SEAT ASSY., EDGE, STD
    SEAT ASSY., EDGE, STD
  • 2
    2683074 COVER ASSY., EDGE, STD
    COVER ASSY., EDGE, STD
  • 3
    7080550 GROMMET, RELATCH, 1", BOTT.
    GROMMET, RELATCH, 1", BOTT.
  • 4
    7080549 GROMMET, RELATCH, 1", TOP
    GROMMET, RELATCH, 1", TOP
  • 5
    7080548 TWISTLOCK, RELATCH, 1", W/HOLE
    TWISTLOCK, RELATCH, 1", W/HOLE
  • 6
    7621337 RIVET
    RIVET
  • 7
    4030024 BULB, TAILLIGHT
    BULB, TAILLIGHT
  • 8
    4030045 BULB
    BULB
  • 9
    5430423 LENS, TAILLIGHT
    LENS, TAILLIGHT
  • 10
    7511840 SCREW
    SCREW
  • 11
    5433341 HOUSING-TAILLIGHT
    HOUSING-TAILLIGHT
  • 12
    7555727 WASHER
    WASHER
  • 13
    7621319 RIVET
    RIVET
  • 14
    7558301 WASHER, FLAT
    WASHER, FLAT
  • 15
    7517219 SCREW
    SCREW
  • 16
    5631194 NUT-SEAT
    NUT-SEAT
  • 17
    2460399 HARNESS, TAILLIGHT
    HARNESS, TAILLIGHT
  • 18
    7542122 NUT-NYLOK
    NUT-NYLOK
  • 19
    7555960 WASHER, FLAT
    WASHER, FLAT
  • 20
    7670021 NUT, SPEED
    NUT, SPEED
  • 21
    7512193 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 22
    5810947 FOAM, SEAL
    FOAM, SEAL
  • 23
    7052215 PICK-UP, FUEL, W/MESH
    PICK-UP, FUEL, W/MESH
  • 24
    7080768 RING, COMPRESSION
    RING, COMPRESSION
  • 25
    5432981 GROMMET-1/2", NITRILE
    GROMMET-1/2", NITRILE
  • 26
    8350017-600 FUEL LINE, ETHER, RED, 5/16"
    FUEL LINE, ETHER, RED, 5/16"
  • 27
    7080003 CLAMP, HOSE
    CLAMP, HOSE
  • 28
    7052269 FITTING
    FITTING
  • 29
    8350020-600 FUEL LINE, ETHER, VLT, 3/8"
    FUEL LINE, ETHER, VLT, 3/8"
  • 30
    2520262 FUEL TANK ASSY. (INCL. 23-31)
    FUEL TANK ASSY. (INCL. 23-31)
  • 31
    7052095 FITTING, 90 DEG, 1/8
    FITTING, 90 DEG, 1/8
  • 32
    8450061-600 LINE, FUEL, 3MMX7MM
    LINE, FUEL, 3MMX7MM
  • 33
    7080804 CABLE TIE-RELEASABLE, 5 1/2"
    CABLE TIE-RELEASABLE, 5 1/2"
