DRIVE TRAIN ASSEMBLY W/ DRIVE BELT для Polaris WIDETRAK LX (S00SU4BS) - 2000 года выпуска`
-
№АртикулНазвание
-
17713401 RING, RETAININGRING, RETAINING
-
27555922 BUSHINGBUSHING
-
31910217 DISC, BRAKE ASSY.DISC, BRAKE ASSY.
-
57517291 BOLTBOLT
-
65410630 O-RINGO-RING
-
77517446 SCREWSCREW
-
81332219 COUPLER ASSY., W/GREASE LONG (19 TEETH) (INCL. FITTING AND SCREW)COUPLER ASSY., W/GREASE LONG (19 TEETH) (INCL. FITTING AND SCREW)
-
87080437 ZERK, GREASEZERK, GREASE
-
91332218 JACKSHAFT ASSY., W/BEARING (19 TEETH) (INCL. 10)JACKSHAFT ASSY., W/BEARING (19 TEETH) (INCL. 10)
-
103514525 BEARINGBEARING
-
117542324 NUTNUT
-
127558402 WASHER, STEELWASHER, STEEL
-
135222393 FLANGETTE 2-BOLTFLANGETTE 2-BOLT
-
145830135 GASKET, JACKSHAFT 2-BOLTGASKET, JACKSHAFT 2-BOLT
-
155222647 FLANGETTE, GREASABLEFLANGETTE, GREASABLE
-
167512377 BOLTBOLT
-
177556509 WASHER, SPECIALWASHER, SPECIAL
-
187721204 KEY, SQUAREKEY, SQUARE
-
205431482 SPACER, INLET SHAFTSPACER, INLET SHAFT
-
217555806 WASHERWASHER
-
227571626 WASHER, SPRINGWASHER, SPRING
-
237515502 BOLTBOLT
-
243211070 BELT, DRIVE (28 DEGREE)BELT, DRIVE (28 DEGREE)
-
253280116 ADAPTER, DRIVE W/ZERKADAPTER, DRIVE W/ZERK
-
265830012 GASKET, DRIVE ADAPTORGASKET, DRIVE ADAPTOR
-
273280017 SQUARE KEY SPEEDOMETERSQUARE KEY SPEEDOMETER
-
285241178 FLANGETTE, OFFSET W/HOLEFLANGETTE, OFFSET W/HOLE
-
293280019 BUSHING METAL SPEEDOBUSHING METAL SPEEDO
-
301012945 FLANGETTE ASSY., W/SCREWSFLANGETTE ASSY., W/SCREWS
-
311590285 DRIVESHAFT ASSY. (INCL.29-31)DRIVESHAFT ASSY. (INCL.29-31)
-
321332198 COUPLER ASSY., W/GREASE ZERK (19TEETH)COUPLER ASSY., W/GREASE ZERK (19TEETH)
-
337517292 BOLTBOLT
-
347515474 BOLTBOLT
-
355210759 SPACER (.063) (OPT)SPACER (.063) (OPT)
-
355210760 SPACER (.080) (OPT)SPACER (.080) (OPT)
-
355210764 SPACER (.020) (OPT)SPACER (.020) (OPT)
-
355211065 SPACER (.010) (OPT)SPACER (.010) (OPT)
-
367542423 NUTNUT
