ENGINE MOUNTING для Mercruiser - 888 (2 BBL.) FORD 302 V-8 1971-1977 3108723 AND UP

  • №
    Артикул
    Название
  • 1
    61413 BRACKET, MOUNTING (FRONT - STARBOARD)
    SERIAL 00000000-03245667
    BRACKET, MOUNTING (FRONT - STARBOARD)
    SERIAL 00000000-03245667
  • 1
    61413 BRACKET, MOUNTING (FRONT - PORT)
    SERIAL 00000000-03245667
    BRACKET, MOUNTING (FRONT - PORT)
    SERIAL 00000000-03245667
  • 1
    61854 BRACKET, MOUNTING (FRONT - PORT AND STARBOARD)
    SERIAL 03245668-09999999
    BRACKET, MOUNTING (FRONT - PORT AND STARBOARD)
    SERIAL 03245668-09999999
  • 2
    10-30155 SCREW, ADJUSTING - MOUNTING BRACKET
    SERIAL 03245668-09999999
    SCREW, ADJUSTING - MOUNTING BRACKET
    SERIAL 03245668-09999999
  • 3
    11-22024 NUT, MOUNTING BRACKET SCREW
    SERIAL 03245668-09999999
    NUT, MOUNTING BRACKET SCREW
    SERIAL 03245668-09999999
  • 4
    16-65743 STUD, MOUNTING BRACKET TO BLOCK (3")
    STUDS (REF. NO. 4) WITH NUTS (REF. NO 6) REPLACE ORIGINAL SCREWS
    STUD, MOUNTING BRACKET TO BLOCK (3")
    STUDS (REF. NO. 4) WITH NUTS (REF. NO 6) REPLACE ORIGINAL SCREWS
  • 4
    16-65737 STUD, MOUNTING BRACKET TO BLOCK (2-5/8")
    STUDS (REF. NO. 4) WITH NUTS (REF. NO 6) REPLACE ORIGINAL SCREWS
    STUD, MOUNTING BRACKET TO BLOCK (2-5/8")
    STUDS (REF. NO. 4) WITH NUTS (REF. NO 6) REPLACE ORIGINAL SCREWS
  • 5
    12-54426 WASHER, MOUNTING BRACKET STUD
    STUDS (REF. NO. 4) WITH NUTS (REF. NO 6) REPLACE ORIGINAL SCREWS
    WASHER, MOUNTING BRACKET STUD
    STUDS (REF. NO. 4) WITH NUTS (REF. NO 6) REPLACE ORIGINAL SCREWS
  • 6
    11-34933 NUT, MOUNTING BRACKET STUD
    STUDS (REF. NO. 4) WITH NUTS (REF. NO 6) REPLACE ORIGINAL SCREWS
    NUT, MOUNTING BRACKET STUD
    STUDS (REF. NO. 4) WITH NUTS (REF. NO 6) REPLACE ORIGINAL SCREWS
  • 7
    10-47654 SCREW, CLAMP - ADJUSTING TRUNNION (2-3/4")
    SCREW, CLAMP - ADJUSTING TRUNNION (2-3/4")
  • 8
    13-32993 LOCKWASHER, CLAMP ADJUSTING TRUNNION SCREW
    LOCKWASHER, CLAMP ADJUSTING TRUNNION SCREW
  • 9
    54-47528 CLAMP, ADJUSTING TRUNNION SCREW
    CLAMP, ADJUSTING TRUNNION SCREW
  • 10
    11-82670814 NUT, CLAMP ADJUSTING TRUNNION SCREW
    NUT, CLAMP ADJUSTING TRUNNION SCREW
  • 11
    60421A2 BRACKET ASSEMBLY, MOUNTING - FRONG
    BRACKET ASSEMBLY, MOUNTING - FRONG
  • 12
    60429 MOUNT, MOUNTING BRACKET
    MOUNT, MOUNTING BRACKET
  • 13
    12-48611 WASHER, MOUNTING BRACKET
    WASHER, MOUNTING BRACKET
  • 14
    10-52156 SCREW, ADJUSTING TRUNNION (4 1/2")
    SCREW, ADJUSTING TRUNNION (4 1/2")
  • 15
    14-48467 TAB WASHER, ADJUSTING TRUNNION SCREW
    TAB WASHER, ADJUSTING TRUNNION SCREW
  • 16
    11-47525 NUT, JAM - ADJUSTING TRUNNION SCREW
    NUT, JAM - ADJUSTING TRUNNION SCREW
  • 17
    17-22116 PIN, ROLL - JAM NUT
    PIN, ROLL - JAM NUT
  • 18
    47518 TRUNNION, ADJUSTING - MOUNTING BRACKET
    TRUNNION, ADJUSTING - MOUNTING BRACKET
  • 19
    47986 BRACKET, MOUNTING - ENGINE
    SERIAL 00000000-03245667
    BRACKET, MOUNTING - ENGINE
    SERIAL 00000000-03245667
  • 20
    10-48254 SCREW, MOUNTING BRACKET ATTACHING (2 1/8")
    SERIAL 00000000-03245667
    SCREW, MOUNTING BRACKET ATTACHING (2 1/8")
    SERIAL 00000000-03245667
  • 21
    13-31848 LOCKWASHER, MOUNTING BRACKET SCREW
    SERIAL 00000000-03245667
    LOCKWASHER, MOUNTING BRACKET SCREW
    SERIAL 00000000-03245667
