AUDIO WARNING SYSTEM для Mercruiser - 300 TEMPEST GM 350 V-8 1985-1986 6668677 THRU 0B430367

  • №
    Артикул
    Название
  • 1
    48952 SWITCH, WATER TEMPERATURE
    SWITCH, WATER TEMPERATURE
  • 2
    13-26996 LOCKWASHER, TEMPERATURE SWITCH (#10)
    LOCKWASHER, TEMPERATURE SWITCH (#10)
  • 3
    11-45076 NUT, TEMPERATURE SWITCH (10-32)
    NUT, TEMPERATURE SWITCH (10-32)
  • 4
    22-92949 BUSHING, REDUCER-TEMPERATURE SWITCH
    BUSHING, REDUCER-TEMPERATURE SWITCH
  • 5
    87-805605A1 SWITCH PRESSURE
    SWITCH PRESSURE
  • 6
    11-45076 NUT, PRESSURE SWITCH TERMINAL (10-32)
    NUT, PRESSURE SWITCH TERMINAL (10-32)
  • 7
    816492A14 BUZZER HOUSING ASSEMBLY
    BUZZER HOUSING ASSEMBLY
  • 8
    816492A14 TIMER, TEMPERATURE BUZZER
    TIMER, TEMPERATURE BUZZER
  • 9
    68878A6 HORN
    HORN
  • 10
    10-69013 SCREW, HORN ATTACHING
    SCREW, HORN ATTACHING
  • 11
    84-86044A4 WIRE ASSEMBLY, TAN/BLUE (36")
    WIRE ASSEMBLY, TAN/BLUE (36")
  • 12
    84-88032A1 WIRE ASSEMBLY, TAN/BLUE (20")
    WIRE ASSEMBLY, TAN/BLUE (20")
  • 13
    84-86322A8 WIRE ASSEMBLY, BLACK (8")
    WIRE ASSEMBLY, BLACK (8")
  • 14
    22-52930 TEE
    TEE
  • 15
    22-38992 BUSHING, TEMPERATURE SWITCH
    BUSHING, TEMPERATURE SWITCH
