CARBURETOR ASSEMBLY, COMPLETE для Mercruiser - 325 MIE GM 427 V-8 1968-1974 2278747 THRU 3780449
-
№АртикулНазвание
-
-1347-3342 CARBURETOR ASSEMBLY, COMPLETE (AUTOMATICV CHOKE)
SERIAL 00000000-03042730CARBURETOR ASSEMBLY, COMPLETE (AUTOMATICV CHOKE)
SERIAL 00000000-03042730 -
-1347-3689A1 CARBURETOR ASSEMBLU, COMPLETE ELECTROC CHOKECARBURETOR ASSEMBLU, COMPLETE ELECTROC CHOKE
-
-1347-4533A1 CARBURETOR ASSEMBLY, COMPLETE (AUTOMATIC CHOKE)
SERIAL 03042731-09999999CARBURETOR ASSEMBLY, COMPLETE (AUTOMATIC CHOKE)
SERIAL 03042731-09999999 -
11397-3310 AIR HOR ASSEMBLY (AUTOMATIC CHOKE)
ELECTRIC CHOKE SERIAL 00000000-03042730AIR HOR ASSEMBLY (AUTOMATIC CHOKE)
ELECTRIC CHOKE SERIAL 00000000-03042730 -
11397-4585 AIR HORN ASSEMBLE (AUTOMATIC CHOKE)
ELECTRIC CHOKE SERIAL 03042731-09999999AIR HORN ASSEMBLE (AUTOMATIC CHOKE)
ELECTRIC CHOKE SERIAL 03042731-09999999 -
21397-5640 LEVER, AIR VALVE LOCKOUT (AUTOMATIC CHOKE)
SERIAL 00000000-03042730LEVER, AIR VALVE LOCKOUT (AUTOMATIC CHOKE)
SERIAL 00000000-03042730 -
390-8M0143356 ROLL PINM LOCKOUT LEVER
SERIAL 00000000-03042730ROLL PINM LOCKOUT LEVER
SERIAL 00000000-03042730 -
41397-3313 HOLDER KIT, SECONDARY METERING RODHOLDER KIT, SECONDARY METERING ROD
-
51397-3312 METERING ROD, SECONDARY (AUTOMATIC CHOKE)
ELECTRIC CHOKE SERIAL 00000000-03042730METERING ROD, SECONDARY (AUTOMATIC CHOKE)
ELECTRIC CHOKE SERIAL 00000000-03042730 -
51397-3312 METERING ROD, SECONDARY (AUTOMATIC CHOKE)
SERIAL 03042731-09999999METERING ROD, SECONDARY (AUTOMATIC CHOKE)
SERIAL 03042731-09999999 -
610-48137 SCREW, AIR HORN TO FLOAT BOWL (3/8")SCREW, AIR HORN TO FLOAT BOWL (3/8")
-
710-34370 SCREW, AIR HORN TO FLOAT BOWL (1")SCREW, AIR HORN TO FLOAT BOWL (1")
-
810-48395 SCREW, AIR HORN TO FLOAT BOWL (3")SCREW, AIR HORN TO FLOAT BOWL (3")
-
91397-5638 LEVER, ACRUATING - PUMP (AUTOMATIC CHOKE)
SERIAL 00000000-03042730LEVER, ACRUATING - PUMP (AUTOMATIC CHOKE)
SERIAL 00000000-03042730 -
91397-5638 LEVER, ACTUATING - PUMP (AUTOMATIC CHOKE)
SERIAL 03042731-09999999LEVER, ACTUATING - PUMP (AUTOMATIC CHOKE)
SERIAL 03042731-09999999 -
1090-8M0143356 ROLL PIN, HINGE - PUMP LEVERROLL PIN, HINGE - PUMP LEVER
-
1190-8M0143356 PUMP ASSEMBLYPUMP ASSEMBLY
-
1290-8M0143356 SPRING, PUMP RETURNSPRING, PUMP RETURN
-
1390-8M0143356 NEEDLE AND SEAT ASSEMBLYNEEDLE AND SEAT ASSEMBLY
-
1490-8M0143356 GASKETM NEEDLE AND SEATGASKETM NEEDLE AND SEAT
-
1590-8M0143356 PULL CLIP, FLOAT NEEDLEPULL CLIP, FLOAT NEEDLE
-
1690-8M0143356 GASKET, AIR HORNGASKET, AIR HORN
-
1790-8M0143356 METERING ROD, PRIMARYMETERING ROD, PRIMARY
-
1890-8M0143356 JET, PRIMARYJET, PRIMARY
-
191397-3321 CHOKE SHAFT AND LEVER ASSEMBLY (AUTOMATIC CHOKE)
SERIAL 00000000-03042730CHOKE SHAFT AND LEVER ASSEMBLY (AUTOMATIC CHOKE)
SERIAL 00000000-03042730 -
191397-4326 CHOKE SHAFT AND LEVER ASSEMBLY (AUTOMATIC CHOKE)
SERIAL 00000000-03042730CHOKE SHAFT AND LEVER ASSEMBLY (AUTOMATIC CHOKE)
SERIAL 00000000-03042730 -
--52730 CHOKE LEVER
ELECTRIC CHOKECHOKE LEVER
ELECTRIC CHOKE -
2010-27881 SCREW, CHOKE LEVER ATTACHING
ELECTRIC CHOKESCREW, CHOKE LEVER ATTACHING
ELECTRIC CHOKE -
2113-26994 LOCKWASHER, CHOKE LEVER SCREW
ELECTRIC CHOKELOCKWASHER, CHOKE LEVER SCREW
ELECTRIC CHOKE -
2211-21270 NUT, CHOKE LEVER SCREW
ELECTRIC CHOKENUT, CHOKE LEVER SCREW
ELECTRIC CHOKE -
231397-3322 VALVE, CHOKE - CHOKE SHAFT (AUTOMATIC CHOKE)
SERIAL 00000000-03042730VALVE, CHOKE - CHOKE SHAFT (AUTOMATIC CHOKE)
SERIAL 00000000-03042730 -
231397-3632 VALVE, CHOKE - CHOKE SHAFT(ELECTRIC CHOKE)VALVE, CHOKE - CHOKE SHAFT(ELECTRIC CHOKE)
-
231397-4587 VALVE, CHOKE - CHOKE SHAFT (AUTOMATIC CHOKE)
SERIAL 03042731-09999999VALVE, CHOKE - CHOKE SHAFT (AUTOMATIC CHOKE)
SERIAL 03042731-09999999 -
2410-48139 SCREW, CHOKE VALVE TO CHOKE SHAFTSCREW, CHOKE VALVE TO CHOKE SHAFT
-
251397-3327 FLOAT ASSEMBLYFLOAT ASSEMBLY
-
2617-48140 PIN, HINGE - FLOATPIN, HINGE - FLOAT
-
271397-3323 LEVER, INTERMEDIATE CHOKELEVER, INTERMEDIATE CHOKE
-
281397-3332 BATTLE, FLOAT BOWLBATTLE, FLOAT BOWL
-
291397-3324 ROD, CHOKEROD, CHOKE
-
3090-8M0143356 CLIP, CHOKE RODCLIP, CHOKE ROD
-
311397-3319 CAM, FAST IDLE (AUTOMATIC CHOKE)
SERIAL 00000000-03042730CAM, FAST IDLE (AUTOMATIC CHOKE)
SERIAL 00000000-03042730 -
321397-3318 ROD, VACUUM CONTROLROD, VACUUM CONTROL
-
3390-8M0143356 CLIP, VACUUM CONTROL RODCLIP, VACUUM CONTROL ROD
-
341397-3316 BRACKET ASSEMBLY, VACUUM CONTROL (AUTOMATIC CHOKE)
SERIAL 00000000-03042730BRACKET ASSEMBLY, VACUUM CONTROL (AUTOMATIC CHOKE)
SERIAL 00000000-03042730 -
341397-3339 BRACKET ASSEMBLY, VACCUUM CONTROL (AUTOMATIC CHOKE)
ELECTRIC CHOKE SERIAL 03042731-09999999BRACKET ASSEMBLY, VACCUUM CONTROL (AUTOMATIC CHOKE)
ELECTRIC CHOKE SERIAL 03042731-09999999 -
3510-48138 SCREW, VACUUM CONTROL BRACKET TO FLOAT BOWLSCREW, VACUUM CONTROL BRACKET TO FLOAT BOWL
-
361397-3317 CONTROL ASSEMBLY, VACUUMCONTROL ASSEMBLY, VACUUM
-
371397-3320 HOSE BACUUMHOSE BACUUM
-
381397-3328 POWER PISTON ASSEMBLYPOWER PISTON ASSEMBLY
-
3924-48142 SPRING, METERING ROD - PRIMARYSPRING, METERING ROD - PRIMARY
-
401397-3329 RETAINER, POWER PISTONRETAINER, POWER PISTON
-
411397-3326 RETAINER, PUMP DISCHARGE BALLRETAINER, PUMP DISCHARGE BALL
-
4290-8M0143356 BALL, PUMP DISCHARGEBALL, PUMP DISCHARGE
-
4324-48141 SPRING, POWER PISTONSPRING, POWER PISTON
-
441397-3331 INSERT, FLOAT BOWLINSERT, FLOAT BOWL
-
451397-3325 FLOAT BOWL ASSEMBLYFLOAT BOWL ASSEMBLY
-
4610-48144 SCREW, IDLE STOPSCREW, IDLE STOP
-
4724-34373 SPRING, IDLE STOP SCREWSPRING, IDLE STOP SCREW
-
483302-9032 SPRING, FILTER NUTSPRING, FILTER NUT
-
4935-53336Q FILTER, FUEL INLETFILTER, FUEL INLET
-
501397-3330 NUT, FILTER - FUEL INLETNUT, FILTER - FUEL INLET
-
5190-8M0143356 GASKET, FILTER NUTGASKET, FILTER NUT
-
5290-8M0143356 GASKET, THROTTLE BODYGASKET, THROTTLE BODY
-
531397-3333 ROD, PUMPROD, PUMP
-
5490-8M0143356 CLIP, PUMP RODCLIP, PUMP ROD
-
551397-3334 THROTTLE BODY ASSEMBLY (AUTOMATIC CHOKE)
SERIAL 00000000-03042730THROTTLE BODY ASSEMBLY (AUTOMATIC CHOKE)
SERIAL 00000000-03042730 -
551397-4588 THROTTLE BODY ASSEMBLY (AUTOMATIC CHOKE)
SERIAL 03042731-09999999THROTTLE BODY ASSEMBLY (AUTOMATIC CHOKE)
SERIAL 03042731-09999999 -
5690-8M0143356 IDLE NEEDLE, THROTTLE BODYIDLE NEEDLE, THROTTLE BODY
-
5724-33050 SPRING, IDLE NEEDLESPRING, IDLE NEEDLE
-
5810-48145 SCREW, THROTTLE BODY TO FLOAT BOWL(AUTOMATIC CHOKE - SERIAL)SCREW, THROTTLE BODY TO FLOAT BOWL(AUTOMATIC CHOKE - SERIAL)
-
581397-4333 SREW, THROTTLE BODY TO FLOAT BOWL(AUTOMATIC CHOKE - SERIAL)SREW, THROTTLE BODY TO FLOAT BOWL(AUTOMATIC CHOKE - SERIAL)
-
591397-3335 LEVER, CAM (AUTOMATIC CHOKE)
ELECTRIC CHOKE SERIAL 00000000-03042730LEVER, CAM (AUTOMATIC CHOKE)
ELECTRIC CHOKE SERIAL 00000000-03042730 -
601397-3336 LEVER, FAST IDLE
ELECTRIC CHOKE SERIAL 00000000-03042730LEVER, FAST IDLE
ELECTRIC CHOKE SERIAL 00000000-03042730 -
6110-48146 SCREW, LEVER AND CAM TO THROTTLE BODY
ELECTRIC CHOKE SERIAL 00000000-03042730SCREW, LEVER AND CAM TO THROTTLE BODY
ELECTRIC CHOKE SERIAL 00000000-03042730 -
--1397-3315 SPRING AND CAM KIT, AIR VALVESPRING AND CAM KIT, AIR VALVE
-
--823426A1 OVERHAUL KITOVERHAUL KIT
-
--823426A1 GASKET SETGASKET SET
-
--823426A1 OFF ENGINE KITOFF ENGINE KIT
