Carburetor & Throttle Linkage(185) для Mercruiser - 205 (4 BBL.) GM 262 V-6 1985-1987 0A331455 THRU 0B527954

  • №
    Артикул
    Название
  • 1
    15414A7 COVER, Plastic, Carburetor
    COVER, Plastic, Carburetor
  • 2
    37-137237 DECAL, Carburetor Cover
    (185)
    DECAL, Carburetor Cover
    (185)
  • 2
    37-137237 DECAL, Carburetor Cover
    (185 Alpha One)
    DECAL, Carburetor Cover
    (185 Alpha One)
  • 3
    86271 FLAME ARRESTOR, Carburetor
    FLAME ARRESTOR, Carburetor
  • 4
    12-86400 WASHER, Sealing
    WASHER, Sealing
  • 5
    11-826709109 NUT, (.250-28), Silencer Adaptor
    NUT, (.250-28), Silencer Adaptor
  • 6
    32-8M0062669 HOSE, Vent, Carburetor (11-1/4")
    HOSE, Vent, Carburetor (11-1/4")
  • 7
    54-53101 CLAMP, Vent Hose
    CLAMP, Vent Hose
  • 8
    97850T ELBOW, 90 Degree, Breather, Vent Hose
    ELBOW, 90 Degree, Breather, Vent Hose
  • 8
    47957 CONNECTOR, Vent Hose (Straight)
    CONNECTOR, Vent Hose (Straight)
  • 9
    23-8M0071559 GROMMET, Rocker Cover
    GROMMET, Rocker Cover
  • 10
    3310-807764A1 CARBURETOR ASSEMBLY (MerCarb)
    CARBURETOR ASSEMBLY (MerCarb)
  • 11
    70125A02 COVER, Choke
    COVER, Choke
  • 12
    10-33047 SCREW, Choke Cover
    SCREW, Choke Cover
  • 13
    13-26995 LOCKWASHER, (#8) Stainless Steel, Cover Screw
    LOCKWASHER, (#8) Stainless Steel, Cover Screw
  • 14
    54-33036 RETAINER, Cover Screw
    RETAINER, Cover Screw
  • 15
    22-97282 CONNECTOR, Carburetor
    CONNECTOR, Carburetor
  • 16
    16-97012 STUD, Flame Arrestor
    STUD, Flame Arrestor
  • 17
    11-8267139 NUT, Jam, Flame Arrestor
    NUT, Jam, Flame Arrestor
  • 18
    16-46857 STUD, (5/16 x 1-7/8), Carburetor
    Attach With Screw
    STUD, (5/16 x 1-7/8), Carburetor
    Attach With Screw
  • 18
    16-8M0113177 STUD, (.312 x 1.500), Carburetor
    Attach With Studs
    STUD, (.312 x 1.500), Carburetor
    Attach With Studs
  • 18
    16-70237 STUD, (.312-18/.312-24 x 2.620), Carburetor
    Attach With Studs
    STUD, (.312-18/.312-24 x 2.620), Carburetor
    Attach With Studs
  • 19
    11-29250 NUT, (.312-24), Carburetor Stud
    Attach With Screw
    NUT, (.312-24), Carburetor Stud
    Attach With Screw
  • 19
    11-862902 NUT, (.9375-24), Carburetor Stud
    Attach With Studs
    NUT, (.9375-24), Carburetor Stud
    Attach With Studs
  • 20
    10-74822 SCREW, (.312-18 x 3.500), Carburetor
    Attach With Screw
    SCREW, (.312-18 x 3.500), Carburetor
    Attach With Screw
  • 21
    12-20084 WASHER, (.328 x .562 x .062), Carburetor Stud
    WASHER, (.328 x .562 x .062), Carburetor Stud
  • 22
    805489T BRACKET, Throttle Cable
    BRACKET, Throttle Cable
  • 23
    16-38525 STUD, Throttle Cable
    STUD, Throttle Cable
  • 24
    12-24664 WASHER, (M4 x 20)
    WASHER, (M4 x 20)
  • 25
    11-826709109 NUT, (.250-28)
    NUT, (.250-28)
  • 26
    27-8079821 GASKET, Carburetor to Intake Manifold
    GASKET, Carburetor to Intake Manifold
  • 27
    10-98509 SCREW, Throttle Cable to Carburetor
    SCREW, Throttle Cable to Carburetor
  • 28
    12-56681 WASHER, (.203 x .500 x .032), Throttle Cable Screw
    WASHER, (.203 x .500 x .032), Throttle Cable Screw
  • 29
    23-57938 BUSHING, Throttle Cable Screw
    BUSHING, Throttle Cable Screw
  • 30
    23-34948 SPACER, Throttle Cable Screw
    SPACER, Throttle Cable Screw
  • 31
    12-847883 WASHER, Throttle Cable Screw
    WASHER, Throttle Cable Screw
  • 32
    11-8267086 NUT, (#10-32), Throttle Cable Screw
    NUT, (#10-32), Throttle Cable Screw
