ELECTRICAL COMPONENTS(1) для Mariner - 30 (2 CYL.) 0G055314 THRU 0G760299

  • №
    Артикул
    Название
  • 1
    11-64015 NUT, (.250-20)
    NUT, (.250-20)
  • 2
    13-26992 LOCKWASHER, (.250) Stainless Steel
    LOCKWASHER, (.250) Stainless Steel
  • 3
    84-88807A16 CABLE ASSEMBLY, (4.00 Inches) Black
    ELECTRIC
    CABLE ASSEMBLY, (4.00 Inches) Black
    ELECTRIC
  • 4
    89-850187T1 SOLENOID ASSEMBLY
    ELECTRIC
    SOLENOID ASSEMBLY
    ELECTRIC
  • 5
    23-818968 BUSHING
    ELECTRIC
    BUSHING
    ELECTRIC
  • 6
    25-818967 GROMMET
    ELECTRIC
    GROMMET
    ELECTRIC
  • 7
    10-40011129 SCREW, (M6 x 25) Stainless Steel
    SCREW, (M6 x 25) Stainless Steel
  • 8
    11-26419 NUT, (#8-32) Brass
    NUT, (#8-32) Brass
  • 9
    84-825004A1 CABLE ASSEMBLY (RED)
    ELECTRIC
    CABLE ASSEMBLY (RED)
    ELECTRIC
  • 10
    84-88439A4 CABLE ASSEMBLY, Battery - Negative
    ELECTRIC
    CABLE ASSEMBLY, Battery - Negative
    ELECTRIC
  • 11
    85-97861 INSULATOR
    INSULATOR
  • 12
    8275101 RETAINER
    RETAINER
  • 13
    398-832074A11 STATOR
    (MANUAL)
    STATOR
    (MANUAL)
  • 14
    10-4013930 SCREW, (M5 x 30)
    SCREW, (M5 x 30)
  • 15
    25-62457 O-RING
    O-RING
  • 16
    99021A14 TRIGGER
    TRIGGER
  • 17
    84-11149A14 HARNESS ASSEMBLY, Adapter
    HARNESS ASSEMBLY, Adapter
  • 18
    8302361 PLATE, Electrical
    PLATE, Electrical
  • 19
    23-822003 BUSHING
    BUSHING
  • 20
    25-822002 GROMMET
    GROMMET
  • 21
    12-4002316 WASHER
    WASHER
  • 22
    10-40011129 SCREW, (M6 x 25) Stainless Steel
    SCREW, (M6 x 25) Stainless Steel
  • 23
    10-82129114 SCREW, (M6 x 14)
    SCREW, (M6 x 14)
  • 24
    823251A5 TPM ASSEMBLY
    TPM ASSEMBLY
  • 25
    10-82239320 SCREW, (M5 x 20)
    SCREW, (M5 x 20)
  • 26
    84-824456A2 HARNESS ASSEMBLY, Engine
    (MANUAL)
    HARNESS ASSEMBLY, Engine
    (MANUAL)
  • 27
    84-824477A4 HARNESS ASSEMBLY, Engine
    (ELECTRIC)
    HARNESS ASSEMBLY, Engine
    (ELECTRIC)
  • 28
    86-638131 TERMINAL BLOCK
    MANUAL
    TERMINAL BLOCK
    MANUAL
  • 29
    10-82239312 SCREW, (M5 x 12)
    MANUAL
    SCREW, (M5 x 12)
    MANUAL
  • 30
    10-62568 SCREW, (#10-16 x .375)
    MANUAL
    SCREW, (#10-16 x .375)
    MANUAL
  • 31
    54-816311T TIE STRAP, (8.00 Inches)
    TIE STRAP, (8.00 Inches)
  • 32
    8M0084173 REGULATOR, Voltage
    ELECTRIC
    REGULATOR, Voltage
    ELECTRIC
  • 33
    54-54457 J CLIP
    ELECTRIC
    J CLIP
    ELECTRIC
  • 34
    84-88807A20 CABLE ASSEMBLY (BLACK-11 IN.)
    ELECTRIC
    CABLE ASSEMBLY (BLACK-11 IN.)
    ELECTRIC
  • 35
    10-82129135 SCREW, (M6 x 35)
    SCREW, (M6 x 35)
  • 36
    84-88807A29 CABLE ASSEMBLY (BLACK-9 IN.)
    CABLE ASSEMBLY (BLACK-9 IN.)
  • 37
    10-878609 SCREW, (#10-16 x .600)
    SCREW, (#10-16 x .600)
  • 38
    827509A12 CDM ASSEMBLY
    CDM ASSEMBLY
  • 39
    10-82129114 SCREW, (M6 x 14)
    SCREW, (M6 x 14)
  • 40
    84-813715A13 CABLE KIT, Ignition
    CABLE KIT, Ignition
  • 41
    85-63709A1 BOOT/TERMINAL KIT
    BOOT/TERMINAL KIT
  • 42
    33-816737Q SPARK PLUG (NGK# BP8H-N-10)
    SPARK PLUG (NGK# BP8H-N-10)
  • 42
    33-816837Q SPARK PLUG (NGK#BPZ-8H-N-10)
    SPARK PLUG (NGK#BPZ-8H-N-10)
  • 43
    88-19637A4 SOCKET ASSEMBLY, Fuse
    ELECTRIC
    SOCKET ASSEMBLY, Fuse
    ELECTRIC
  • 44
    88-812619 FUSE, Yellow - 20 Ampere
    ELECTRIC
    FUSE, Yellow - 20 Ampere
    ELECTRIC
