TANK - SEAT - COVER для Ktm 525 MXC RFS - 2004 года выпуска`

№

Артикул

Название
1

59007013600 FUEL TANK CPL. 13L

FUEL TANK CPL. 13L

0 ₽
2

50307011000 SCREW SEAT FASTENING D=6X23/18

SCREW SEAT FASTENING D=6X23/18

620 ₽
3

50307014000 TANK ROLLER 12X26X12

TANK ROLLER 12X26X12

2 720 ₽
4

0015060123 HH COLLAR SCREW M 6X12 WS=8

HH COLLAR SCREW M 6X12 WS=8

500 ₽
5

59007008044 FILLER CAP CPL. SMALL

FILLER CAP CPL. SMALL

6 630 ₽
6

59007009000 GASKET FOR FILLER CAP HIGH

GASKET FOR FILLER CAP HIGH

1 840 ₽
7

31007107001 PVC-HOSE 6X9 MM PER METRE

PVC-HOSE 6X9 MM PER METRE

1 550 ₽
8

51030022000 ANGLE PIECE 90 DEGREE M10X1

ANGLE PIECE 90 DEGREE M10X1

1 110 ₽
9

59003001055 SUPORT BUSHING TANKROLLER

SUPORT BUSHING TANKROLLER

1 810 ₽
10

0015060453 HH COLLAR SCREW M 6X45 WS=8

HH COLLAR SCREW M 6X45 WS=8

470 ₽
11

58307105200 FUEL COCK CPL. OFF-ON-RES

FUEL COCK CPL. OFF-ON-RES

12 070 ₽
12

0770130023 O-RING 13,00X2,30

O-RING 13,00X2,30

850 ₽
13

0017060203 SPECIAL SCREW T60 6X20 WS=6

SPECIAL SCREW T60 6X20 WS=6

290 ₽
14

58031005000 CLAMP YDNAC 10128 12MM

CLAMP YDNAC 10128 12MM

760 ₽
15

59007016000 FUEL HOSE 7,5X13MM

FUEL HOSE 7,5X13MM

3 100 ₽
20

59407040000 SEAT

SEAT

34 860 ₽
21

59407040050 SEAT COVER

SEAT COVER

10 440 ₽
30

59029099000 TOOL SET

TOOL SET

0 ₽
