REAR HUB для Kawasaki GTO - 2000 года выпуска

№

Артикул

Название
112

112V0630 BOLT, UPSET

BOLT, UPSET
317

317B0800 NUT, HEX, SMALL, 8MM

NUT, HEX, SMALL, 8MM
550

550D3025 PIN, COTTER, 3.0X25

PIN, COTTER, 3.0X25
601

601B6004G BEARING, BALL, #6004G

BEARING, BALL, #6004G
601A

601B6202G BEARING, BALL, #6202G

BEARING, BALL, #6202G
601B

601B6302UG BEARING, BALL, #6302UG

BEARING, BALL, #6302UG
41035

41035-1320 PANEL, ASSY., BRAKE, REAR

PANEL, ASSY., BRAKE, REAR
41048

41048-1087 SHOE, BRAKE

SHOE, BRAKE
41050A

41050-1096 CAM, BRAKE

CAM, BRAKE
41053

41053-1024 LEVER, BRAKE CAM

LEVER, BRAKE CAM
41068

41068-1369 AXLE, REAR

AXLE, REAR
41072

41072-007 NUT, 6MM

NUT, 6MM
41085

41085-013 INDICATOR, BRAKE SHOE

INDICATOR, BRAKE SHOE
42005

42005-057 DRUM, ASSY., REAR

DRUM, ASSY., REAR
42010

42010-037 COLLAR, L=57

COLLAR, L=57
42033

42033-1104 COUPLING, ASSY., REAR

COUPLING, ASSY., REAR
42036

42036-1043 SLEEVE, L=63.5

SLEEVE, L=63.5
42041

42041-1452 SPROCKET, HUB (38 TEETH)

SPROCKET, HUB (38 TEETH)
42045

42045-015 NUT, 20MM

NUT, 20MM
92001

92001-021 BOLT, 8X36

BOLT, 8X36
92015

92015-1765 NUT, CASTLE, 14MM

NUT, CASTLE, 14MM
92022

92022-1269 WASHER, LOCK

WASHER, LOCK
92027

92027-1482 COLLAR, REAR AXLE

COLLAR, REAR AXLE
92027A

92027-1729 COLLAR, 20X26X15.5

COLLAR, 20X26X15.5
92049

92049-1487 SEAL, OIL, KCY26X42X8

SEAL, OIL, KCY26X42X8
92055

92055-004 O-RING, BRAKE CAM

O-RING, BRAKE CAM
92057

92057-1476 CHAIN, DRIVE

CHAIN, DRIVE
92058

92058-1078 JOINT, CHAIN, DRIVE

JOINT, CHAIN, DRIVE
92081

92081-1766 SPRING, BRAKE SHOE

SPRING, BRAKE SHOE
92161

92161-1327 DAMPER, REAR HUB SHOCK

DAMPER, REAR HUB SHOCK
