STEERING POST AND TIE ROD ASSEMBLY для Arctic Cat ZR 120 (BLACK) [S2015ZRAAAUSB] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    1705-313 POST, STEERING (BLACK)
    POST, STEERING (BLACK)
  • 2
    1606-765 GRIP, HANDLE
    GRIP, HANDLE
  • 3
    0302-165 HOUSING,THROTTLE CONTROL
    HOUSING,THROTTLE CONTROL
  • 4
    1623-828 PIN - 1/4D X 1 5/8
    PIN - 1/4D X 1 5/8
  • 5
    8070-318 PIN, SPRING
    PIN, SPRING
  • 6
    0611-022 DECAL, ENGINE STOP SWITCH
    DECAL, ENGINE STOP SWITCH
  • 7
    0109-609 LEVER, CONTROL
    LEVER, CONTROL
  • 8
    0123-231 RING, RETAINING
    RING, RETAINING
  • 9
    0302-147 HOUSING,BRAKE CONTROL
    HOUSING,BRAKE CONTROL
  • 10
    0609-007 SWITCH, STOP - ENGINE
    SWITCH, STOP - ENGINE
  • 11
    1705-444 COVER, HANDLEBAR PAD
    COVER, HANDLEBAR PAD
  • 12
    1605-107 PAD, HANDLEBAR
    PAD, HANDLEBAR
  • 13
    8020-040 SCREW,CAP-HFH 1/4-20 X 0.750 Z & Y
    SCREW,CAP-HFH 1/4-20 X 0.750 Z & Y
  • 14
    3008-040 CLAMP, HEAT SENSOR,M12
    CLAMP, HEAT SENSOR,M12
  • 15
    0705-896 BRACKET, STEERING SUPPORT - PAINTED (BLACK)
    BRACKET, STEERING SUPPORT - PAINTED (BLACK)
  • 16
    0605-444 BEARING, STEERING POST
    BEARING, STEERING POST
  • 17
    8047-366 NUT,HEX FLG-NY LOCK 1/4-20 GR F Z & Y
    NUT,HEX FLG-NY LOCK 1/4-20 GR F Z & Y
  • 18
    1623-423 NUT, FLEX-LOC 5/16-24 UNF Z & Y
    NUT, FLEX-LOC 5/16-24 UNF Z & Y
  • 19
    8050-247 WASHER,FLAT- 5/16 X .688 X .065 Z & Y
    WASHER,FLAT- 5/16 X .688 X .065 Z & Y
  • 20
    8004-135 SCREW,CAP-HH 5/16-24 X1.50 G5 Z & Y
    SCREW,CAP-HH 5/16-24 X1.50 G5 Z & Y
  • 21
    1703-853 TIE ROD - ASSEMBLY (INC. 22-23)
    TIE ROD - ASSEMBLY (INC. 22-23)
  • 22
    0623-260 ...NUT, HEX - LEFT-HAND THREAD
    ...NUT, HEX - LEFT-HAND THREAD
  • 23
    0123-144 ...NUT, HEX - RIGHT-HAND THREAD
    ...NUT, HEX - RIGHT-HAND THREAD
  • 24
    8060-484 RIVET, BLIND-DH SS53 ZINC
    RIVET, BLIND-DH SS53 ZINC
  • 25
    1707-444 SUPPORT, STEERING POST (BLACK)
    SUPPORT, STEERING POST (BLACK)
  • 26
    0630-138 SWITCH, TETHER (INC. 27)
    SWITCH, TETHER (INC. 27)
  • 27
    0630-139 ...CORD, TETHER SWITCH
    ...CORD, TETHER SWITCH
  • 28
    0687-229 CABLE, BRAKE
    CABLE, BRAKE
  • 29
    1602-100 SPRING, RETURN - BRAKE
    SPRING, RETURN - BRAKE
  • 30
    0123-788 TIE, CABLE - 8 IN.
    TIE, CABLE - 8 IN.
  • 31
    0687-231 CABLE, THROTTLE (120) (INC. TWO NO. 32)
    CABLE, THROTTLE (120) (INC. TWO NO. 32)
  • 32
    8053-212 ...WASHER,LOCK-1/4 EXT TOOTH TYP A Z & Y
    ...WASHER,LOCK-1/4 EXT TOOTH TYP A Z & Y
